7. Dimension

Size(mm)
Model
SC947
SC948
SC949
SC950
SC951
※
SC952
Note: The picture above is the specification diagram of the pool heat pump, for technician's installation
and layout reference only. The product is subject to adjustment periodically for improvement without
further notice.
Name
A
410 645
410 645
410 645
410 710
410 710
410 710
Above data is subject to modification without notice.
B C D
404 430
404 430
404 430
404 430
404 430
404 430
7
E F G
890 250 75
890 290 75
890 280 75
1060 320 75
1060 460 75
1060 640 75
H
658
658
658
658
758
958
