2 . Ball bearing 699
9. Shift fork
10. Spring clip
11. Wobble bearing and HK0908
needle bearing
1 . HK0908 needle bearing
2 . Wobble bearing
12. Clutch
13. Compression spring
14. Cylindrical gear assy
1 . Cylindrical gear
2 . Ball bearing 607
15. Screw M 4*12
16. Washerφ4
17. End shield
18. Lampshade
19. Screw M3.9*16
20. Motor housing
21. Button
22. Rotor
23. Stator assy
1 . Stator
2 . Wiring box
3 . Upper cover of wiring box
4 . Screw M2 .2*10
5 . Switch
6 . PCB assy
7 . Patch panel
24. Rubber particles
25. End shield
26. Auxiliary handle Assy
1 . Clamping band
2 . T-bolt
3 . Clamp holder
4 . Clamp
5 . Compression spring
6 . Auxiliary handle
27. Depth Guage
28. O-ring
