power supply. Standby Mode Power is always available as long as input power is present. The Fan supply (optional ） i s controlled by Remote
ON/OFF control.
5． ． ． ． Mounting Directions
5-1. Output Derating according to the Mounting Directions
Recommended standard mounting method is (A), Method (B, C, D, E) are also possible. Refer to the output derating below.
Load (%) of derating curve indicates output power. The E-cap life under Method D and Method E maybe be shorter than 3years, the detail
please see the official data.
(A) Standard mounting
Inhibit
5-2. Output Derating vs. Ambient temperature
Make sure that the specified temperature range is maintained.
All manuals and user guides at all-guides.com
(B) (C)
- 6 -
TDK-Lambda
CUS350M
Instruction Manual
(D) (E)
