DESCRIPTION OF THE APPLIANCE
1
2
3
5
3
click
4
click
2
2
1
5 4
EN 16
Fruit and vegetable drawer with automatic humidity control
The drawer at the bottom of the refrigerator is intended for storing fruit
and vegetables. It provides humidity and prevents the food from drying
out. The humidity in the drawer is regulated automatically, depending
on the type and amount of inserted food.
To remove a drawer from the rails, pull the drawer fully out. Lift the back
of the drawer (1). Pull the drawer to you (2) and then lift the drawer from
the rails.
6
To fit the drawer onto the rails, pull the two rails fully out. Place the
4 drawer on the rails (3). In the front, press the drawer and the rails
towards each other on the right and the left side until you hear a "click"
(4). Press the back of the drawer downwards if necessary (5). Finally,
slide the drawer on the rails fully in (6).
Door compartments
The height of the door compartments is adjustable. Lift the
compartment out of the groove and fit it in the required position. Each
compartment can carry a maximum weight of 5 kg. The bottom door
compartment is suitable for bottles.
Glass shelves
3 The shelves are made from safety glass. To change the height of a
shelf, lift the front of the shelf (1). Take hold of the back and pull the
3
shelf slightly forwards (2). Move the shelf to a higher or lower position
(3).
To remove a shelf from the refrigerator, lift the front of the shelf (4). Take
5
hold of the back and pull the shelf out of the appliance (5).
