On the inside of the front cover illustrations have been included of damaged and worn (rejected)
pivots and camsegments:
1. One complete tooth not sharp and one damaged
EN
2. Two teeth damaged for 50%
06
3. One tooth damaged for 100% and one tooth damaged for 50%
4. Two rings damaged for 100%
5. Interior ring damaged for 100%
These areas of damage, precisely as wear, are not covered by the warranty.
In most cases however the areas of damage are much less extensive. In doubtful cases an author-
ised repairer should assess the clamp.
4. How to operate the clamp
IPBHZ - IPHGZ - IPHGUZ lifting clamps are suitable for horizontal lifting and transport of steel
plates, beams and structures.
See illustrations 3 - 7 for part reference.
1. Open the clamp by pulling the latch lever (A) into the direction of the arrow (3).
2. Place the clamp securely on the material to be lifted, so that the jaw of the clamp rests against
the plate or flange (E). Keep base against the load (4).
3. Pull the latch lever (A) towards the lifting eye (D). The clamp will now close and will remain on
the plate in pretensioned position, allowing lifting to commence (5).
4. As soon as the load is at its destination let the crane hook descend until the clamp is fully free
of load, meaning that the lifting chain is no longer taut and the lifting eye (D) of the clamp can
move freely (6).
5. The clamp may now be removed from the load by pulling the latch lever (A) into the direction of
the arrow and simultaneously keeping the base of the body (N) against the load. The clamp will
open and may now be removed from the load (7).
5. A reliable clamp, a secure basis for lifting
10 Year warranty preventive maintenance procedure:
Parts should be replaced only when they no longer meet our standards.
10 Year warranty repair procedure:
During every repair service the most critical parts, being camsegment will be replaced and, when
necessary, any rejected parts.
Please consult www.thecrosbygroup.com/resources/crosbyip-10-year-guarantee for more infor-
mation on maintenance procedures.
Maintenance without 10 year warranty: Annually clamps are subjected to inspection* and parts will
be replaced only when they no longer meet our standards.
*CrosbyIP authorised repairer
