Owner's manual
PoE function, then connect the switch to the computer or with use of a suitable
power adapter).
2. configure computer's network card for connection with the camera: in Internet
Protocol Version 4 (TCP/IPv4) set IP address 192.168.1.X (X is any number from
2-254 with an exception for number 86); subnet mask 255.255.255.0 and default
gateway 192.168.1.1.
3. open Internet Explorer browser. Enter camera's default IP address (192.168.1.86)
into browser's address bar. Then enter user name (default login: admin)
and password (default password: 123456). Press "Login" to log into camera
configuration page.
4. the browser now displays camera's configuration page.
5. set static IP address from IP pool assigned by the router. To do this, go to "Setup"
tab > "Network" > "TCP/IP". Set static address (set mode as "static").
6. camera can be connected to your router. Once the camera is connected, log into
previously set camera's address (enter the address into browser's address bar) for
real time video preview. Please remember the computer needs to be connected to
the same local network as camera!
SGSEyE APP MANAGEMENT (for mobile devices running Android and iOS)
1. Open the Internet Explorer browser on a device running Windows which is also
connected to the same local network as the camera. Enter camera's IP address
into browser's address bar and log-in. Go to "Setup" tab" > "Network" > "P2P".
Detailed information on the camera will be displayed on the right side of the screen
(including Device ID and password (data necessary for SGSEye app camera
access).
2. Download "SGSEye" application from Google Play Store or App Store.
3. Install the app.
4. Once the installation is completed, SGSEye app icon will appear on the list of
installed apps of your smartphone.
5. Open the app.
