Environmental Impact; Specifications; Accessories, Spare Parts - nosiboo pro Bedienungsanleitung

10. Environmental impact

Dispose of the device in accordance with your
local recycling and waste disposal practices and
requirements.
The Colibri head does not present a risk to the environ-
ment and can be disposed of as household waste.

11. Specifications

Max. motor performance: 500 W
Adjustable motor performance: 200-390 W
Performance: 370 VA
Differential pressure: 0.04-0.08 bar
Max. air flow: 30-42 l/min
Power supply: 230 V 50 Hz
IP class: IP21
Protection class: II
Type of applied parts: BF
Applied parts: the complete housing
Operation type: no continuous operation
Operation length: on 15 min/appr. off 50 min
Duration of continuous use: max 15 min.
Safety switch release time: after 15 minutes
Tripping temperature of the thermal switch: 95 °C
Average housing temperature: 30-35 °C after 1 min continuous use
Noise level: 60-70 dB
Operating temperature range: -10 °C... +40 °C
Operating relative humidity: max. 75%
Storage and transportation temperature: -20 °C...+65 °C
Storage and transportation relative humidity: 10...95%
Expected life of the housing (electrical parts): 3 years
Expected life of the Colibri head: 3 months
Diameter of the nasal insertion end of the standard nose tip:
max. 7.0 mm
Length of the nasal insertion end of the standard nose tip:
max. 8.0 mm
Diameter of the nasal insertion end of the newborn's nose tip:
max. 4.9 mm
Length of the nasal insertion end of the newborn's nose tip:
max. 12.6 mm
Weight: 1090 g
Dimensions (housing, W x H x D): 198 x 162 x 172 mm
Dimensions (complete package): 180 x 180 x 225 mm
MD Category: II.a
NBOG: MD1102
MDD/MDR: MDD Legacy Device
Actor EUDAMED No.: HU-MF-000004252
We reserve the right to make technical changes.

12. Accessories, spare parts

In the European Union, parts can be
ordered from the specialist service
station:
Attract Kft. H-7622 Pécs, Siklósi út 1/1 - Hungary
Tel.: +36 72 551 642 (Mo-Fr: 8 am – 4 pm)
E-mail: customerservice@nosiboo.com
In countries outside the European Union, spare parts
are available at the distributors of Nosiboo products.
For information on the warranty, please see the link below:
https://en.nosiboo.eu/downloads/
The manufacturer shall not be held responsible for the
failure of products from unauthorised import sources!
Power cord EU
NO-01-022-A6-0WE1
Power cord UK
NO-01-022-A6-0WM3
Connecting unit
NO-01-050-H2-7BXX * blue
*
NO-01-050-H2-7PXX pink
NO-01-050-H2-7GXX * green
!
CAUTION
