Locate the Electrical Service Panel and switch all applicable
3.
breakers to the OFF position.
Hold the Mount in the desired location, ensuring it is level,
4.
using a Spirit/Bubble Level. Mark the location of the Pilot
Holes, using a Pencil.
Drill the Pilot Hole(s), using a Concrete Drill with the
5.
appropriate size/type of Masonry Drill Bit. The depth of the
holes should equal the length of the Mounting Screws.
Insert the Concrete Anchors into the Pilot Holes and tap
6.
into place, using a Mallet.
Align the holes, located in the Mount, with the Pilot Holes.
7.
Insert the Mounting Screws through the Mount and into the
8.
Concrete Anchors.
Tighten the Mounting Screws, using a Ratcheting Socket
9.
Wrench with an appropriately sized Hex Socket.
Note: If the product features keyhole mounting, first secure
the hardware to the wall, then hang the product from the
mounting hardware. Tighten the mounting screws after
hanging the product.
Follow the steps to attach the Equipment to the Mount,
10.
located in the User Manual.
