Mix mode

1 All chase programs will run synchronously.
2 All programs can be controlled by the Speed Fader or each program's speed may be controlled individually
( section Running a program with a standard speed).
3 Press the MODE SELECT button and select CHASE/SCENES mode.
4 Press the PARK button to select MIX CHASE mode. A red LED will indicate this selection.

Dimmer display

1 The display is used to display intensity percentage or absolute DMX value.
2 To change between percentage and absolute value: Press and hold the SHIFT Button. While holding down
the SHIFT button, press the % or 0-255 button to switch between percentage and absolute values.
3 If the display reads, for example, "076", it means a percentage value 76%. If the display reads "076", it means
the DMX value 76.

Blind and Home

1 The Blind function takes channels temporally out from a chase, when the chase is running, and gives you
manual control over the channel.
2 Press and hold the BLIND button and tap the relative FLASH button you want to temporarily take out of the
chase.
3 To return to normal chase again press and hold the HOME Button and push the FLASH Button you want to
return to normal chase.

Add and Kill

1 The ADD/KILL changes the mode of the Flash buttons. As a basic setting, the flash buttons are in Add mode.
Then multiple scenes can be triggered via the Flash buttons.
2 Tapping the ADD/KILL button enables the Kill mode (corresponding LED lights). Then pressing any flash
button will kill any other scenes or programs (they will keep running internally).

Setting MIDI IN

1 Tap the FLASH button 1 three times while holding down the RECORD button. The display reads CHI
indicating MIDI IN channel setup is available.
2 Tap the FLASH button numbered from 1-16 to assign MIDI IN Channel 1-16. The relevant channel LED lights
indicating MIDI IN channel is set.

Setting MIDI OUT

Tap the FLASH button 2 three times while holding down the RECORD button. The display reads CHO
1
indicating MIDI IN channel setup is available.
2 Tap the FLASH button numbered from 1-16 to assign MIDI OUT Channel 1-16. The relevant channel LED
lights indicating MIDI OUT channel is set.

Exit MIDI setting

While holding down the

Receiving MIDI file dump

Tap the FLASH button 3 three time while holding down the RECORD button. The display reads IN indicating the
controller is ready to receive MIDI file dump.
RECORD button tap the

MIDI SETTINGS

REC EXIT button to exit MIDI setting.
