Program scenes

1 Enable Program mode.
2 Select the 1-48 SINGLE mode by tapping the MODE SELECT button. This will give you control of all 48
channels as you program. Be sure that MASTER A and B faders are both set to maximum (Master A is at its
maximum when positioned all the way up, while Master B is at its maximum when positioned all the way
down).
3 Create a desired scene using Channel Faders 1-48. At 0% or DMX 255, these faders should be at 10 position.
4 Once the scene is satisfactory, tap the RECORD button to program the scene as a step into the memory.
5 Repeat step 3 and 4 until all desired steps have been programmed into memory.
6 Select a chase bank to store your program. Tap the PAGE button select a page (page 1-4) to store your
scenes.
7 Press a FLASH button between 25-48 while holding down the RECORD button. All LEDs will flash indicating
the scenes have been programmed into memory.
8 If you are not satisfied with the scene or scenes, you may tap the REC CLEAR button while pressing and
holding the RECORD button. All LEDs will flash, indicating the scenes have been cleared.
9 You can continue programming or exit. To exit Program
.
EXAMPLE
Program a 16-step chase with channel 1-32 at full in sequence and assign into Flash button 25 of Page 1.
1 Enable Program mode.
Push the MASTER A and B faders to maximum position and the FADE fader to top.
2
Tap the MODE SELECT button to select 1-48 SINGLE mode.
3
4 Push Channel fader 1 to the top position, its LED lights at full intensity.
5 Tap the RECORD button to program this step into memory.
6 Repeat steps 4 and 5 until you've programmed Channel faders 1-32.
7 Tap the RECORD button causing page 1 LED to light.
8 Tap the FLASH button 25 while holding down the RECORD button, all LEDs will flash indicating you've
programmed the chase into memory.

Enable edit mode

1 Enable Program mode.
2 Use the PAGE button to select the page the program you wish to edit is on.
3 Tap the MODE SELECT button to select CHASE/SCENES mode.
Press and hold down the EDIT button.
4
While holding down the EDIT button, tap the FLASH button that corresponds to program you wish to edit.
5
6 Release the FLASH button, the relevant scene LED should light indicating you are in the Edit mode.

Erase a program

1 Enable Program mode.
2 Use the PAGE button to select the page that the program you wish to erase is on.
While holding down the RECORD button, tap the FLASH button (25-48) twice. Release the two buttons. All
3
LEDs flash, indicating the program is erased.

Erase all programs

1 Press and hold the RECORD button.
2 Tap the FLASH buttons 1, 4, 2 and 3 in sequence while holding the RECORD button. All LEDs will flash,
indicating all programs stored in memory have been erased.
26 • EN
