Assembly
(You will need a screwdriver.)
1. Carefully remove all components from the package and check to ensure nothing is
damaged. If equipment is damaged,immediately notify the retailer from where the
equipment was purchased.
2. The sand filter should be placed on solid, level ground, preferably a concrete slab.
Position the sand filter so the Ports and Control Valve are accessible for operation,
servicing and winterizing.
3. EN60335-2-41 TEST standard requires the sand filter to be vertically fixed on
ground or a certain pedestal made of wood or concrete before use to prevent the
sand filter from accideutally falling. Fully assembled sand filter will exceed 18kg. The mounting holes should
be 8mm in diameter and spaced 110mm apart. Use two bolts and nuts with a maximum of 8mm in diameter
to fasten the sand filter to the pedestal.
Load pool-grade filter sand.
NOTE: Use only special pool-grade filter sand, free of all limestone or clay: #20 Silica sand 0.45-0.85mm,
approximately one 18kg bag should suffice. If you do not use the recommended size filter sand, filtering
performance will be reduced and the sand filter may damaged, thereby voiding warranty.
NOTE: To avoid damaging the Skimmer when adding sand, pour some water into the Bottom Tank to submerse
the Skimmer on the Collector Hub.
NOTE: SAND NOT INCLUDED.
Nut
C
Nut
C
Connect to the pool
For 38mm(1.5in)
connection
S-S-005003/21.0x28.5cm/58400EU/ 1000gal 欧规砂滤器说明书/JS-YF-2016-B-08872-英
MAX.
MIN .
Nut
C
5
110mm Ø8mm
C
