The system menu of the basic unit
The menu item "System settings" offers the parameter setup of the basic unit.
By selecting "System settings" the user accesses the following OH 40 A system parameters:
Update OH40A
MultiUpdate Mod
UID License Code
LIC Load OH40A
LIC Load Module
NIT Load Module
CfgLoad
CfgSave
StatSave
IP-Addr
ETH-NetMask
ETH-Gateway
Port
FM-Att
Out-Att
I-Supply
SW-Version
HW-Version
BL-Version
Factory Reset
Restart OH40A
Restart System
Restore Web SW
With the ◄ key, you step back from the "System settings" menu to the module selection menu.
When the entry "system settings" is selected in the module selection menu and the ◄ button pushed
afterwards, the device will move to standby immediately.
Saving changes:
- 18 -
Insert USB memory stick > Select OH40A-File (Image)
Insert USB memory stick > Modules will be successively updated with latest
software
UID for Remote
License: 8C061251 (example)
The Web-UI (optional feature) is locked by default.
The UID License Code is needed to purchase and obtain a license key.
This key is to be entered via Web-UI or USB memory stick.
Insert USB memory stick > Search for Unlock code and activate it
Insert USB memory stick > Search for License-File and transfer it to selected
module.
LIC to: 2 OH77 (example) > Insert USB memory stick
NIT Load (Import external NIT) NIT to: 2 OH77 (example) > Insert USB memory
stick
Insert USB memory stick > config. file is uploaded, the modules are
configured accordingly
(the modules have to remain at the same plug-in positions as in CfgSave)
Insert USB memory stick > the configuration of all modules is described in the
config. file
Insert USB memory stick > status (e.g. PLL-lock) of all modules is decribed in
the status file
IP address setting, e.g. 192.168.000.100
Subnet-Mask, e.g. 255.255.255.000
Gateway address setting, e.g. 192.168.000.001
(router/server for internet)
Standard-Port for http = 80
FM-Attenuation
0...30 dB (attenuation at the FM input)
Out-Attenuation
0...15 dB (attenuation at the FM output)
Current
I: <8750 mA (power consumption of installed modules)
Displays the current software version of OH 40 A
Displays the current hardware version of OH 40 A
Displays the current boot loader version of OH 40 A
Reset OH 40 A to delivery status (all settings are deleted,
the activation key remains)
Software-Reset OH40A
Reset OH40A Headend (all modules)
Restore the factory default settings of the web interface
By leaving the "System settings" menu.
Without any user setting the standby display appears after 60 seconds,
settings are not being stored.
