WARNING! When draining the water out of the water
tank all necessary precautions must be taken to
prevent damages from flowing out water.
IMPORTANT! In Denmark, Sweden, Norway and
Finland, the connection of the water heater to the
public water supply may only be performed using a
suitable pressure reducing
regulations must be observed.

Electrical connection

WARNING! Any electrical connection may only be
performed when the water heater is filled with water.
IMPORTANT!
The water heater is powered by direct
current. The water heater is protected against electric
shock "class III" and may only be supplied with safety
extra-low voltage (SELV). Only power sources
recommended by the manufacturer may be
connected. A faulty and/or unsuitable power supply
involves a high risk and is likely to cause an accident.
The connection cables of the device must be replaced
if they are damaged.
IMPORTANT! Photovoltaic modules may
parallel.
connected in When connecting more than
one photovoltaic module, always use a suitable
connector for parallel connection. For more
information, refer to the illustration "Parallel PV-
Connector". Connecting photovoltaic modules in
series will damage the water heater.
Parallel PV-Connector
Connection of PV-modules in parallel configuration only!
Serial connection will damage the unit!
www.fothermo.com
valve. The local
ONLY
Pay attention to correct polar-
ity when connecting!
The electrical connection of the water heaters is
performed using MC4 plugs. Check the functionality
of the appliance after the electrical connection has
been performed. When all supply connections are
removed, the water heater is completely
disconnected from the power sources.
CONNECTION OF PV-MODULES:
IMPORTANT!
connection of PV modules may only be carried out by
a qualified person and may not endanger third
parties. When installing the photovoltaic modules, the
locally prevailing rules and laws must be complied
with.
IMPORTANT!
tripping over them or getting caught. There is a risk of
injury. The cables must be fastened in such a way that
no tensile load is applied to the connectors.
Furthermore, it must be ruled out that the cables and
connectors rub against surfaces and edges (e.g. in
wind). The cables must not lie in water permanently.
IMPORTANT!
maximum of 60 resp. 120 cells and an open-circuit
voltage of 42.4 V may be connected.
•
be
•
Dimensioning of the required photovoltaic power:
•
•
•
•
The installation and electrical parallel
Keep cables out of the way to avoid
Only photovoltaic modules with a
Photovoltaic modules
connected correctly using the factory
supplied MC4 plugs.
You may connect up to five modules in
parallel. Depending on the module, this
corresponds to an MPP output of
approximately 1500 W .
p
The higher the number of hours of
sunshine per day, the smaller the
required PV power.
The warmer the water taken from the
pipeline, the lower the required PV
power.
Dimension the required photovoltaic
power according to the months with the
lowest solar radiation in which the
photovoltaic water heater will be in
operation.
The greater the amount of hot water
consumed per day, the larger the PV
power required.
EN
