Design and Function

4.1

Overview

Pos. Description
1 Inputs and outputs
(power connection, CAN-Y, CAN-X, D-IN/OUT F1/F2)
2 Input module A (option)
3 Input module B (option)
4
Communication ports (USB Host, 2x USB Device, LAN)
5
On/Off key
6
Context-sensitive function keys
7 Screen (touchscreen)
8 Shock protection
INFORMATION
Further information on the connections and input modules is
provided in the detailed operating manual available online at
www.webtec.com or in the device itself in Menu > Settings
> Information > UserManual.
1 2
8
Design and Function
3
7
4
5
6
