NOTICE: The optimum maximum engine revolution has been set at the factory as follows:
Model Engine
RTX 50 Honda GX100
RTX 50R Honda GXR120
RTX 60 Honda GX100
RTX 60R Honda GXR120
RTX 68 Honda GX100
RTX 68R Honda GXR120
RTX 70 Honda GX100
RTX 70R Honda GXR120
RTX 80D
DO NOT alter this setting since irregular vibration or damage to the gear transmission mechanism can
CAUTION
result, and both engine and machine warranties will be automatically voided.
Lifting
Where it is necessary to use lifting equipemnt to position the RTX
• NEVER leave the engine running whilst transporting or moving the RTX's
Once the checks listed in the 'Pre-Start' section have been carried out, you may start the engine.
The Altrad Belle RTX
mechanism. As the engine speed is increased the clutch will engage and the engine will drive the crank mechanism.
CAUTION
For correct operation, the engine speed should be set to maximum.
miss-strike and can be severly damaged. The ramming shoe may especially be damaged severely.
• Ensure that the rammer is steered only by using the handle grip. It should only be pushed. The rammer must not be pressed
into the materials being compacted. Excessive pressure on the operating handle will lead to unsatisfactory compaction due to
the fact that the jumping action is reduced.
Transportation.
NEVER
cooled.
Operation at High Altitude
Start & Stop Procedure
Optimum

Operation

ONLY to the lifting point on top of the RTX's operating handle.
23
Maximum RPM
Upper Limit
RTX's
GB
GB
(Petrol Only)
