ViewSonic PG603W Schnellstart Handbuch

PG603W
DLP Projector
Quick Start Guide Przewodnik Szybki start
快速安装说明 Guia de Início Rápido
Ghid de pornire rapidă
快速入門指南
краткое руководство по
빠른 시작 가이드
クイックスタートガイド
началу работы
Ръководство за бърз старт Vodič za brzi početak
Vodič za brzo pokretanje Príručka so stručným návodom
Úvodní příručka Vodnik za hitri začetek
Aan de slag Guía de inicio rápido
Pika-aloitusopas Snabbstartsguide
Guide de démarrage rapide Hızlı Başlangıç Kılavuzu
Schnellstarthandbuch короткий посібник користувача
Οδηγός γρήγορης εκκίνησης Panduan Mulai Cepat
Első lépések ‫دﻟﯾل اﻟﺑدء اﻟﺳرﯾﻊ‬
Guida introduttiva
http://vsweb.us
Download Link
http://vsweb.us/q/dn.php
ViewSonic Projector
4
On Of f
COMP HDMI 1 HDMI 2
Auto
Source
Sync
On Of f
COMP VIDEO HDMI
Auto Source
Sync
Aspect Freeze Pattern Blank
PgUp
Aspect Freeze PgDn Pattern Blank
Color
Mode
PgUp
PgDn
Color
Network
Mode
1
On Off
COMP HDMI 1 HDMI 2
Auto
Source
Sync
Aspect Freeze Pattern Blank
PgUp
PgDn
Color
Mode Network
PG603W
DLP Projector
Quick Start Guide Przewodnik Szybki start
快速安装说明 Guia de Início Rápido
快速入門指南 Ghid de pornire rapidă
빠른 시작 가이드 краткое руководство по
クイックスタートガイド
началу работы
Ръководство за бърз старт Vodič za brzi početak
Vodič za brzo pokretanje Príručka so stručným návodom
Úvodní příručka Vodnik za hitri začetek
Aan de slag Guía de inicio rápido
Pika-aloitusopas Snabbstartsguide
Guide de démarrage rapide Hızlı Başlangıç Kılavuzu
Schnellstarthandbuch короткий посібник користувача
Οδηγός γρήγορης εκκίνησης Panduan Mulai Cepat
Első lépések ‫دﻟﯾل اﻟﺑدء اﻟﺳرﯾﻊ‬
Guida introduttiva
http://vsweb.us
Download Link
http://vsweb.us/q/dn.php
ViewSonic Projector
5 Screws: M4 x 8 (Max. L = 8 mm)
Unit: mm
294
2
2
1
HDMI
IN
USB READER
OUT
USB WiFi
AUDIO
3
4 5
100-240 Vac
50/60 Hz
• 16:10 image on a 16:10 screen
(a)
(d)
(c)
218
(a)
(c)
(d)
• 16:10 image on a 4:3 screen
(a)
(d)
(c)
94
(a)
(c)
(d)
(e): Screen (f): Center of lens
3
MINI
COMPUTER MONITOR OUT USB VIDEO LAN
RS-232
On Off
On Off
COMP VIDEO HDMI
Auto
Sync COMP Source HDMI 1 HDMI 2
Auto
Source
Sync
Aspect Freeze Pattern Blank
PgUp
HDMI
PgDn IN
Color
Mode
USB READER
OUT
USB WiFi
AUDIO
On Of f
Aspect Freeze Pattern Blank
COMP HDMI 1 HDMI 2
PgUp
On Off
Auto
Source
Sync COMP VIDEO PgDn HDMI
Sync Auto Source
Aspect Freeze Pattern Blank Color
Network
PgUp Mode
PgDn
Mode Color
Aspect Freeze Pattern Blank
PgUp
PgDn
(a) Screen Size (b) Projection distance
Color
Network
Mode
m i . n
inch mm inch mm
(b)
60 1524 79 2000
70 1778 92 2333
80 2032 105 2667
90 2286 118 3000
100 2540 131 3333
(f)
(e) 110 2794 144 3667
120 3048 157 4000
130 3302 171 4333
140 3556 184 4667
150 3810 197 5000
(e)
160 4064 210 5333
(f)
170 4318 223 5667
180 4572 236 6000
(b)
(a) Screen Size (b) Projection distance
m i . n
inch mm inch mm
60 1524 74 1887
70 1778 87 2201
(b)
80 2032 99 2516
90 2286 111 2830
100 2540 124 3145
110 2794 136 3459
(f)
120 3048 149 3774
(e) 130 3302 161 4088
140 3556 173 4403
150 3810 186 4717
160 4064 198 5031
(e)
170 4318 210 5346
(f)
180 4572 223 5660
There is 3% tolerance among these numbers due to optical component variations. It is
recommended that if you intend to permanently install the projector, you should
(b)
physically test the projection size and distance using the actual projector in situ before
you permanently install it, so as to make allowance for this projector's optical
characteristics. This will help you determine the exact mounting position so that it best
suits your installation location.
RS-232
MINI
COMPUTER MONITOR OUT USB VIDEO LAN
RS-232
16:10 image on a 16:10 Screen
(d) Vertical offset
(c) Image
height
m a . x m i . n m a . x
inch mm inch mm inch mm inch mm
87 2200 32 808 0.0 0 0.0 0
101 2567 37 942 0.0 0 0.0 0
115 2933 42 1077 0.0 0 0.0 0
130 3300 48 1212 0.0 0 0.0 0
144 3667 53 1346 0.0 0 0.0 0
159 4033 58 1481 0.0 0 0.0 0
173 4400 64 1615 0.0 0 0.0 0
188 4767 69 1750 0.0 0 0.0 0
202 5133 74 1885 0.0 0 0.0 0
217 5500 79 2019 0.0 0 0.0 0
231 5867 85 2154 0.0 0 0.0 0
245 6233 90 2289 0.0 0 0.0 0
260 6600 95 2423 0.0 0 0.0 0
16:10 image on a 4:3 Screen
(d) Vertical offset
(c) Image
height
m a . x m i . n m a . x
inch mm inch mm inch mm inch mm
82 2075 30 762 0.0 0 0.0 0
95 2421 35 889 0.0 0 0.0 0
109 2767 40 1016 0.0 0 0.0 0
123 3113 45 1143 0.0 0 0.0 0
136 3459 50 1270 0.0 0 0.0 0
150 3805 55 1397 0.0 0 0.0 0
163 4151 60 1524 0.0 0 0.0 0
177 4497 65 1651 0.0 0 0.0 0
191 4843 70 1778 0.0 0 0.0 0
204 5189 75 1905 0.0 0 0.0 0
218 5535 80 2032 0.0 0 0.0 0
232 5881 85 2159 0.0 0 0.0 0
245 6226 90 2286 0.0 0 0.0 0
