2.2 Receivers 900 MHz

Basic Data
Dimensions [mm]
Weight [g]
Antenna length [mm]
# of channel outputs
Temperature range [°C]
Supply voltage [V]
Average current [mA]
Real time transmission of telemetry data
Programming
Support satellite receiver Rsat
Power output [dBm]
Receiver sensitivity [dBm]
Frequency [Mhz]
Receivers RSAT 900 and RSAT 900 NG are not compatible!
3

Installation

3.1 Voltage supply

When designing the on-board wiring for your project, always pay
attention to the voltage input range of your receivers and servos.
You can connect supply voltage to the Duplex receivers as
follows:
- directly from the batteries
- via a BEC voltage regulator (either contained in speed
controllers or self contained)
COMPUTER RADIO CONTROL SYSTEM
7
Rsat900
40x22x7
11
2x300
3
-10 to +85
3.5 – 8.4
70
Yes
DC/DS/JETIBOX
No
14
-110
863 - 870 (EU)
902 - 928 (US)
EN
Rsat900 NG
40x22x7
11
2x200
3
-10 to +85
3.5 – 8.4
50
Yes
DC/DS
No
14
-120
863 - 870 (EU)
902 - 928 (US)
