Examples of Rx setup

Classic setup of a single receiver
(for any analogue/digital servos)
- servo impulses are generated on servo outputs
- each output can be assigned to one of the groups from A to H
- servo outputs assigned to one group are generated at the same
time
- between two consecutive servo groups there is a delay of 2.5ms
FailSafe
Enabled
Classic setup of a single receiver (for digital servos)
FailSafe
Enabled
The second receiver as a backup (clone mode)
- monitors existing connection between the transmitter and the
receiver in "Normal" mode
- does not support telemetry (or an indication of the signal
strength)
- works in receiving direction only, it never transmits
- any number of receivers in Clone mode can be operated
simultaneously
FailSafe
Disabled
COMPUTER RADIO CONTROL SYSTEM
SignalFaultDealy OutputPeriod
1.5s
SignalFaultDealy OutputPeriod
1.5s
SignalFaultDealy OutputPeriod
1.5s
17 ms
Auto
17 ms (or Auto)
24
EN
Rx mode
Normal
Rx mode
Normal
Rx mode
Clone
