5. TECHNICAL SPECIFICATIONS

Rated Power Output (RMS)
All channels driven simultaneously
@ 13.8 V into 4 Ohms (THD<0.1%)
Rated Power Output (RMS)
All channels driven simultaneously
@ 13.8 V into 4 Ohms (THD<1%)
Rated Power Output (RMS)
All channels driven simultaneously
@ 13.8 V into 2 Ohms (THD<1%)
Rated Power Output (RMS)
All channels driven simultaneously
@ 13.8 V into 4 Ohms (THD<1%) Bridged
Damping Factor @ 4 Ohms Load All Channels
Signal-to-Noise Ratio (A-Filter Weighted)
All Channels @ full rated power output
Frequency Response (-3dB)
Operation Mode set to FULL,
All Channels driven simultaneously
Channel Separation
All Channels
Input Sensitivity
All channel Pairs
Integrated Cross-Over/Filtering
Slope Rates
Highpass Cross-Over Frequency Range
Lowpass Cross-Over Frequency Range
Fuses
Dimensions (W x H x D)
30
R4100A2 R2180A2
4x85W 2x185W
4x95W 2x190W
4x140W 2x310W
2x280W 1x610W
> 200 > 200
> 95dB > 95dB
10Hz - 40kHz 10Hz - 40kHz
> 55dB > 55dB
0.2V - 9V 0.2V - 9V
12 dB/Octave High- & Lowpass
continuously variable 10 - 400 Hz
continuously variable 30 - 400 Hz
3x25 A 3x25A
384 x 59 x 270 mm 405 x 59 x 270 mm
R2100A2 R1500A2
2x105W 1x355W
2x110W 1x375W
2x150W 1x555W
1x300W n.a.
> 200 > 200
> 95dB > 95dB
10Hz - 40kHz 10Hz - 40kHz
> 55dB > 55dB
0.2V - 9V 0.2V - 9V
2x20A 2x30A
292 x 59 x 270 mm 384 x 59 x 270 mm
