1. Quadrocopter
Spezifikationen Length: 240 mm ● Height: 66 mm ● Lenght Blades: 135 mm ● Fly time: 10 min. ●
Battery: 3.7v 780mAh20C●Battery (Remote): 4x 1.5V"AA" (not incl.)
2. 2.4 GHz Remote
2A on / off switch
2B status LED
2C Short Press: fly home
Long Press: CF Mode
2D Throttle &Left / Right rotation
Press: D / R
2E Short Press: Photo function
Long Press: Video function
2F forward / back / left / right
Short Press: Flips & Rolls
Long Press: Light On & Off
Automatic returning by pressing a button: Briefly press 2C an acoustic signal and the LED at the rear
end of the copter starts flashing. The Copter automatically fly back to you. You exit this operation by
pressing the stick forward.
CF mode. Make sure that the copter is in front of you and facing forward (Red Propeller front) Bind
now the device. Press for 2 seconds on the "headless" mode, to get there. You will hear a tone.
Please press more than 2 seconds to exit the headless mode.
(R250A)
3. FPV
Features: This product uses 5.8G transmission system. The transmission system is about 500 Meter
high anti-jamming efficiency, easy installation. Using HD Camera, 10,92 cm /4.3 inch large-screen
display.
4.Binding of radio transmitter and receiver
4A
4B
4C
4D
2G Trim function
2H Display
2I Throttle trim
2J Left / Right rotation trim
2K Channel and rudder
2L Left / Right trim
2MFront / Back trim
2N remote battery status
The spacecraft on a flat position, the Lipo-Battery
icon in accordiance with direction pushing people
electric socket to position. Body LED flashing
lights at this time not to move the body, makes
the remote controller reads the neutral point of
frequency and gyroscope
Open the power supply control switch, remote
control issued a bit of noise, a few seconds after
the end of the fuselage LED noise, at the same
time often bright, completes to the code
Remove the flight vehicle battery safely at the
conclusion of flight. This should be made into a
post flight habit to acoid unforeseeable problems.
Warning: If left connected in the flight vehicle for
long duration, the battery may be damaged due
to over-discharge, or even become fire hazards
Turn off the transmitter. If transmitter is not to be
used for a long duration, please remove the
battery for storage. Warning: If the AA batteries
are left in the transmitter, potential leakage could
occur which may damage the transmitter, and
create fire hazards
