CHANGING A LED SPOT
When a LED spot of the cooker hood is broken, you can replace it yourself. Follow these steps:
• Unplug the appliance or remove the connector fuse.
• Remove the grease filters and push the spot holder from the inside downwards - figure 1.
• Turn the broken LED clockwise out of the holder - figure 1. Replace the broken LED with a matching type (3.0 W, LED
spot).
• Fit the new LED counter clockwise in the holder and release the holder - figure 2. It will automatically adjust to the right
position.
• Replace the grease filters and plug the appliance in.
1
6

troubleshooting

What to do in case of a malfunction? In most cases, you will be able to correct these faults easily yourself. Please check the
solutions below before contacting the Inventum service department.
The motor is not running
• Is it plugged in correctly?
• Is there a power outage?
• Check the electrical installation.
The performance of the cooker hood is not correct and makes more nois.
• Is the diameter of the exhaust-air pipe correct?
• Is the duct blocked?
• The diameter of the duct must be 150 mm. A smaller diameter can negatively influence the suction of the motor.
• Are the grease filters clean?
• Are the carbon filters not replaced within the last 6 months? Replace the carbon filters.
• Is there enough air supply to replace the extracted air?
7

installation instructions

Read these installation instructions carefully before starting the installation.
Decide whether there is a duct available or if the cooker hood needs to recirculate. We advise to install the cooker hood
with two persons.
• The minimum distance between the supporting surface for the cooking pans on the cooker and the lowest part of the
hood must be:
- 65 cm for an electric, ceramic or induction cooker
- 75 cm for a gas hob
• If the cooker hood is to be fitted to an existing duct no other aplliances, such as a geyser or heater, may be connected to
that same duct.
• The shorter the duct, and the fewer the bends in it, the better the cooker hood will work.
• The connection pipe for the cooker hood has a diameter of 150 mm.
