USB-C Downstream-Anschluss (Unterseite)
A12
B1
Pin
Signalname
A1
GND
A2
SSTXp1
A3
SSTXn1
A4
VBUS
A5
CC1
A6
Dp1
A7
Dn1
A8
SBU1
A9
VBUS
A10
SSRXn2
A11
SSRXp2
A12
GND
RJ45-Anschluss (Anschlussseite)
GREEN
PHY SIDE
GREEN
ORANGE
SHIELD
24
|
Über Ihren Monitor
A1
B12
Pin
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
RJ45
CABLE SIDE
2kV, 1000pF
GROUND
Signalname
GND
SSRXp1
SSRXn1
VBUS
SBU2
Dn1
Dp1
CC2
VBUS
SSTXn2
SSTXp2
GND
Pin Signalname Pin Signalname
1
TD1 +
2
TD1 -
3
TD2 +
4
TD2 -
5
CT
6
CT
7
TD3 +
8
TD3 -
9
TD4 +
10 TD4 -
11
GREEN_OR-
ANGE
12 GREEN_OR-
ANGE
13 GREEN
14 GREEN
