To ride your e-scooter safely:
• Make sure that you are wearing suitable safety equipment.
• Power on the e-scooter.
• Put one foot on the Foot Rest rst, and the other foot on the ground, kick
the scooter to move forward, and slowly press down the accelerating
throttle.
NOTE:
• When accelerating, lean backwards to maintain your centre of gravity.
When decelerating, move your centre of gravity by leaning forward. This
will make your riding more comfortable and safer.
Braking
• To brake correctly, release the accelerating throttle and engage the disc
brake by squeezing the brake lever on the handle bars. By using the
disc brake, the electronic brake will also operate and your scooter will
decelerate and stop. It is also possible to use the fender brake on the
KS1.
NOTE: model KS2 does not have a rear fender brake.
Walk Mode
• While in Walk Mode the brake light will ash to indicate that your scooter
is travailing slowly. When changing to Medium Mode the brake light will
stop ashing.
Using the Kick Stand
• Your e-scooter has a built-in stand which allows it to be parked without
the need to lean it up against anything or having to collapse for storage.
• To use the Kick Stand, use your foot to press it downwards until it locks
in place. Lean the e-scooter so that it rests on the ground. Do not use the
Kick Stand on uneven or soft surfaces.
• To release the Kick Stand, use your foot to push it upwards and into the
body of the scooter. It will lock into place. Ensure that the Kick Stand is
stowed correctly before riding.
• Be careful when deploying the kick stand as it may cause injury if used
incorrectly.
Charging
• Ensure that the battery tted to your e-scooter is charged correctly by
following the instructions as below:
1. Plug the charger lead to the e-scooter charge port. Refer to picture
8 on page 3 for the location of the charging port on your e-scooter.
2. Plug the charger mains lead into the mains wall socket.
• When connected to the battery charger, the battery will start to charge
and the charge indicator will turn red. After the charging is complete, the
charge indicator will turn green.
3. Disconnect the battery charger when fully charged and replace the
rubber cap on the e-scooter charge socket.
NOTES:
• If the scooter is not being used regularly, it is recommended to charge the
battery every month.
• Do not charge the battery outside.
• Do not charge if the cable or scooter is wet.
• Do not charge when the scooter is powered on.
• Do not charge the battery if the ambient temperature is below 1C.
USB Charging Socket
• For your convenience a USB charging socket is located on the display
module. To access the socket, pull the socket cover to one side.
• The USB charging socket is designed to enable your mobile device to be
kept charged while being used with your e-scooter.
SHARP Life App
Add the SHARP Life app to your mobile device to start enjoying the
bene ts of additional functionality. This includes:
Speed monitoring on your device.
Changing the speed/distance units between kilometers and miles.
Setting the maximum speed.
Lock the functions on your e-scooter.
Activation of the cruise control.
Click on "Add Device", when the e-scooter is turned on and the Bluetooth
icon is ashing on the display.
Your device will scan automatically for your e-scooter. Make sure that the
Bluetooth function is enabled on the e-scooter. Allow location services if
requested.
Once the device is found, Bluetooth pairing is complete.
To add your scooter to the App, use one of the methods below:
1. Create groups.
2. Remove device from previous account.
3. When the e-scooter is powered on, press the power button 4 times
quickly.
https://www.sharpconsumer.com/sharp-life-app
Troubleshooting
The e-scooter does not move after start-up.
Cause / Action
The brake has not restored completely, this will interrupt the operation
of the power supply. / Manually reset the brake. This can be achieved by
pushing the brake lever back to its normal position.
The e-scooter moves at low speed or does not move at all.
Cause / Action
Battery is low. / Battery requires replacement.
The motor starts and switches off again.
Cause / Action
Battery is low. / Battery requires replacement.
The controller is damaged. / Controller requires replacement.
The Battery connection is loose. / Battery connections need to be checked.
The battery cannot be charged or has charged slowly.
Cause / Action
Voltage is not correct. / Battery requires replacement.
The battery does not charge.
The Battery life cycle has come to an end. / Battery requires replacement.
The battery charger does not provide power. / Replace the battery charger.
The charging lead is damaged. / Replace the battery charger.
Error codes
It is possible that errors codes may be displayed. The e-scooter will stop
operating under these conditions.
E0 – Communicaition error
E1 – Abnormal current
E2 – Throttle failure
E3 – Brake failure
E4 – MOS failure / Over current failure
E5 – Hall / Motor failure
E6 – Motor failure
E7 – Low voltage error
Should you experience any issues which cannot be resolved, contact your
dealer or SHARP Support or advice.
