5. Loosen the securing screw (B) on the crossbar attachment and remove the crossbar if you have inserted it.
6. Loosen the locking / securing screw (E) on the slider to which the three cross struts are attached.
7. Fold up the cross struts of the tripod.
8. If possible, pack all parts of the system in their original packaging and store the packaging in a dry place protected
from moisture.
Do not use any solvents, alcohols or other chemicals to clean the plastic parts / metal parts.
To remove dirt, dust, oil and grease, etc., use a soft, dry, lint-free cloth.
At the end of its useful life, this product must not be disposed of with normal household waste, but must be
taken to a collection point for the recycling of electrical and electronic equipment. The symbol on the product,
the instructions for use or the packaging indicates this.
The materials are recyclable according to their labeling. By reusing, material recycling or other forms of
recycling old devices, you are making an important contribution to protecting our environment. Please ask the municipal
administration for the responsible disposal point.
SETO WIND-UP CRANK TRIPOD
General data
Number of segments
Adaption
Height (max.)
Maximum load capacity
Special feature
Dimensions approx. (L x W x H)
Transport dimensions approx. (L x W x H) 1,785 x 230 x 190 mm
Weight
Item no.

Maintenance and repair

Disposal

Technical data

3
bolt receiver
3.80 m
50 kg
1 foot height adjustable
1,770 x 240 x 180 mm
16.1 kg
1410000324
