Operation - Setolite WIND-UP Gebrauchsanleitung

ATTENTION!
Make sure that the tripod system is designed for the weight of the luminaire or spotlight. For safe operation, be sure
to follow the instructions of the tripod system.
Danger of tipping over during transport under load
If the tripod is moved without removing the attached luminaire / spotlight, the tripod may tip over and cause injury
as well as property damage. Remove the attached luminaire / spotlight before moving the tripod.
Danger of tipping over on unsuitable ground
If the tripod is placed on soft or uneven ground, the tripod may tip over and cause injury as well as property damage.
Only set up the tripod on level and firm ground.
Danger of tipping over due to overloading
If overloaded, the tripod may tip over and cause injury as well as property damage. Never exceed the maximum load
capacity specified for the tripod.
Assembling the tripod
1. Fold out the tripod legs completely and set up the tripod. Make sure that the guide of the cross struts (F) is extended
downwards as far as it will go. The installation aid (D) can be used as an additional aid.
2. Fix this position with the locking / securing screw (E) on the slide to which the three cross struts are attached.
Tighten the locking / securing screw firmly!
3. The stability of the tripod can be additionally secured with the help of the optionally available bracing set
(item no. 1410000538). To do this, remove the TV spigot (A) or the mast bolt (H) from SETOLITE, put on the bracing
plate included in the bracing set, put on the required TV spigot or mast bolt and tighten it via the locking screw (B).
4. If you want to install a crossbeam: Loosen the locking / securing screw on the bracket for the crossbeam at the
top of the tripod (A), put on the TV spigot (28 mm adapter) and tighten it with the locking / securing screw on the
bracket; put on the crossbeam and fix it in the desired position with the wing nut. Make sure that the weight is
evenly distributed to achieve a central load on the tripod. Follow the instructions of the respective manufacturer.
The maximum load capacity of 50 kg in total must not be exceeded.
If you are not using a crossbeam or a luminaire / spotlight from SETOLITE: Attach the luminaire / spotlight from
SETOLITE to the tripod head by using a mast bolt (H) instead of the TV spigot (A). This is optionally available as an
accessory (item no. 1410960037).
RISK OF INJURY!
If the locking / securing screws are not tight, the respective push rod may retract automatically under the load.
5. Loosen the two locking / securing screws (B) on the upper and lower pipe clamp of the extension pipe.
6. Extend the extension tube to the desired height with the crank (G). Fix the position of the extension tube with the
two locking / securing screws (B) on the upper and lower tube clamps.
7. Slide the locking bolt (C) on the lower pipe clamp into the corresponding hole in the extension pipe.
8. If you want to turn the upper extension tube: Loosen the locking screws (B) on the pipe clamps. Turn the extension
tube to the desired position. Fix the position of the extension tube with the locking screws (B) on the pipe clamps.
RISK OF INJURY!
An unsafe stand of the tripod endangers persons and material in the vicinity. Wind load or impact can cause the
tripod to fall over.
Dismantling the tripod
1. Loosen the locking bolt (C) on the lower pipe clamp.
2. Loosen the two locking / securing screws (B) on the upper and lower pipe clamp and move the extension pipe all the
way down with the crank (G).
3. Tighten the locking / securing screws (B) on the upper and lower pipe clamps.
4. Remove the luminaire / spotlight. Make sure that the load is even when dismantling.
