SATA to 1 x M.2 + 1 x mSATA Converter
English
Description
This Delock converter enables the connection of a M.2 SSD in 2280, 2260, 2242
and 2230 format or an mSATA SSD in half size or full size format. If both slots are
occupied, only the M.2 SSD can be used. The converter will be installed into the
system internally through a SATA 22 pin interface.
Specification
• Connector:
1 x SATA 6 Gb/s 22 pin plug >
1 x 67 pin M.2 key B slot
1 x mSATA slot (full size)
• Interface: SATA
• Supports M.2 modules in format 2280, 2260, 2242 and 2230 with key B or
key B+M based on SATA
• Maximum height of the components on the module: 1.35 mm, application of
double-sided assembled modules supported
• LED indicator for power and activity
• PWM chipset: max. 3 A output current, short circuit protection, in-rush current
suppression, thermal shutdown protection
• Bootable
• Dimensions (LxW): ca. 98 x 65.5 mm
• OS independent, no driver installation necessary
