User manual / Bedienungsanleitung
2. Setup
Select cartridge type operation mode:
Set the switches on the bottom panel of the
• MM operation: Buttons 'gain' not pressed in (load impedance = 47 kOhm)
• MC operation: Buttons 'gain' pressed in (load impedance = 500 Ohm)
Position MM = button not pressed, position MC = button pressed in.
MM Adjustment

Subsonic-Filter:

Set the switches on the bottom panel of the
• Subsonic filter is on: Both buttons 'subsonic' pressed in
• Subsonic filter is off: Both buttons 'subsonic' not pressed in
Subsonic off
All switches are duplicated for the left and right channels.
Please make sure that both corresponding switches are always in the same position.
Before switching any settings be sure to shut off the power to the basic V2
Never cover or put anything on top of the
parts.
If the unit is not in use for an extended period, switch it off.
Page / Seite 6
basic V2
MC Adjustment
basic V2
Subsonic on
- Attention -
basic V2,
chassis as follows:
chassis as follows:
which could lead to overheating of electronic
