English
Description
With this HDMI switch by Delock up to three HDMI devices can be used with
one HDMI monitor, TV or projector. With the button on the device or the remote
control you can switch between the HDMI devices.
Specification
• Connectors:
Input:
3 x HDMI-A 19 pin female
1 x DC 5 V power connector
Output:
1 x HDMI-A 19 pin female
• HDMI port switching: automatic function, via button or via infrared remote
control
• LED indicators for active HDMI port
• High Speed HDMI specification
• Supports 3D displays
• Supports HDCP 1.4 and 2.2
• Resolution up to 3840 x 2160 @ 60 Hz (depending on the system and the
connected hardware)
• Video bandwidth up to 600 MHz / 6 Gbps, max. 18 Gbps
• Power consumption: max. 2.0 W
• Metal housing
• Colour: black
• Dimensions (LxWxH): ca. 80 x 51 x 20 mm
Power supply specification
• Wall power supply
• Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 0.3 A
• Output: 5 V / 1 A
• Ground outside, plus inside
• Dimensions:
inside: ø ca. 2.1 mm
outside: ø ca. 5.5 mm
length: ca. 9 mm
System requirements
• A free HDMI female
• HDMI cable
