Operating Instructions
Power Bank
Item No. 2582120 (PB-17C-M: 20 W 10000 mAh)
Item No. 2582119 (PB-19C-M: 20 W 20000 mAh)
Intended Use
The product is a portable power bank with fast charging, and can supply up to 20 W of power. The built-in
rechargeable battery is charged via USB. The product is protected against overcharging, over-discharging,
and overload.
Contact with moisture must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use
can result in short circuits, fires, electric shocks or other hazards. Read the instructions carefully and
store them in a safe place. Make this product available to third parties only together with its operating
instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery Content
•
Power bank
•
Micro USB cable (27 cm)
•
USB-C
cable (27 cm)
TM
•
Operating instructions
Up-to-Date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown.
Follow the instructions on the website.
Explanation of Symbols
The symbol with the lightning in the triangle is used if there is a risk to your health, e.g. due to an
electric shock.
The symbol with the exclamation mark in the triangle is used to indicate important information in
these operating instructions. Always read this information carefully.
The arrow symbol indicates special information and advice on operation.
Safety Instructions
Read the operating instructions carefully and especially observe the safety information.
If you do not follow the safety instructions and information on proper handling in this
manual, we assume no liability for any resulting personal injury or damage to property.
Such cases will invalidate the warranty/guarantee.
a) General Information
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become dangerous playing
material for children.
• Protect the appliance from extreme temperatures, direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and protect it
from any accidental use. Safe operation can no longer be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height can dam-
age the product.
• Consult an expert when in doubt about the operation, safety or connection of the appliance.
• Maintenance, modifications and repairs must only be completed by a technician or an au-
thorised repair centre.
• If you have questions which remain unanswered by these operating instructions, contact our
technical support service or other technical personnel.
b) Power Bank
• Make sure that the cable is not pinched, kinked or damaged by sharp edges.
• Never use the product immediately after it has been brought from a cold room into a warm
one. The condensation that forms might destroy the product. Allow the product to reach room
temperature before connecting it and putting it to use. This may take several hours.
• Never leave the product unattended during use.
• The housing warms up during use. Ensure that there is sufficient ventilation. Do not cover
the housing!
• Do not store the product in a heated vehicle. Avoid excessive heat (max. 35 °C). Observe the
information in the "Technical data" section.
• Store the product in a cool, dry place when it is not in use.
• Do not short-circuit the USB inputs/outputs.
c) Connected Devices
• Also observe the safety and operating instructions of any other devices which are connected
to the product.
d) LiPo Rechargeable Battery
• The rechargeable battery is permanently built into the product and cannot be replaced.
• Never damage the rechargeable battery. Damaging the casing of the rechargeable battery
might cause an explosion or a fire! Unlike conventional batteries/rechargeable batteries (e.g.
AA or AAA type), the casing of the LiPo rechargeable battery does not consist of a thin sheet
but rather a sensitive plastic film only.
• Never short-circuit the contacts of the rechargeable battery. Do not throw the battery or the
product into fire. There is a danger of fire and explosion!
• Charge the rechargeable battery regularly, even if you do are not using the product. Due to
the rechargeable battery technology being used, you do not need to discharge the recharge-
able battery first.
• Never charge the rechargeable battery of the product unattended.
• When charging, place the product on a surface that is not heat-sensitive. It is normal that a
certain amount of heat is generated during charging.
• Do not charge the power bank and charge any external devices at the same time! This
may result in damage due to overheating.
• Do not charge the power bank using a USB 2.0/3.0 port on your computer. The current
supplied by these ports may not be sufficient, and may damage the computer.
Operating Elements
Item No. 2582120 shown below.
1
2
3
4
5
6
Charging the Power Bank
•
Connect an included cable into the Micro USB input (3) or the USB-CTM input (5) on your power bank.
•
Connect the other end of the cable to a suitable USB power source.
LED Battery Status Indicators
The LED battery status indicators (1) show you how much power is left in the bank. If needed press the
power button (2) once to light the indicators up. Each LED represents 25 % of charge.
Charging Mobile Devices
•
Connect the included charging cable or mobile device cable to a charging output port.
•
The LED battery status indicators will turn off after all devices have been disconnected from the charger.
You can charge up to 3 devices at the same time. The total charging output is 20 W maximum
and will be shared between each connected device.
Care and Cleaning
•
Disconnect the product from any devices and power supply before cleaning.
•
Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as they can
cause damage to the housing and malfunctioning.
•
Clean the product with a dry, fibre-free cloth.
Disposal
a) Product
This symbol must appear on any electrical and electronic equipment placed on the EU market.
This symbol indicates that this device should not be disposed of as unsorted municipal waste
at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose of it
separately from unsorted municipal waste. Spent batteries and accumulators, which are
not enclosed by the WEEE, as well as lamps that can be removed from the WEEE in a
non-destructive manner, must be removed by end users from the WEEE in a non-destructive
manner before it is handed over to a collection point.
Distributors of electrical and electronic equipment are legally obliged to provide free take-back of waste.
Conrad provides the following return options free of charge (more details on our website):
•
in our Conrad offices
•
at the Conrad collection points
•
at the collection points of public waste management authorities or the collection points set up by
manufacturers or distributors within the meaning of the ElektroG
End users are responsible for deleting personal data from the WEEE to be disposed of.
It should be noted that different obligations about the return or recycling of WEEE may apply in countries
outside of Germany.
b) (Rechargeable) batteries
Remove batteries/rechargeable batteries, if any, and dispose of them separately from the product.
According to the Battery Directive, end users are legally obliged to return all spent batteries/rechargeable
batteries; they must not be disposed of in the normal household waste.
Batteries/rechargeable batteries containing hazardous substances are labelled with this
symbol to indicate that disposal in household waste is forbidden. The abbreviations for heavy
metals in batteries are: Cd = Cadmium, Hg = Mercury, Pb = Lead (name on (rechargeable)
batteries, e.g. below the trash icon on the left).
Used (rechargeable) batteries can be returned to collection points in your municipality, our stores or
wherever (rechargeable) batteries are sold. You thus fulfil your statutory obligations and contribute to
environmental protection.
Batteries/rechargeable batteries that are disposed of should be protected against short circuit and their
exposed terminals should be covered completely with insulating tape before disposal. Even empty
batteries/rechargeable batteries can contain residual energy that may cause them to swell, burst, catch fire
or explode in the event of a short circuit.
1 LED battery status indicators
2 Power button
Press once to show the battery status.
Press twice to deactivate the output power.
3 Micro USB input
4 USB-A output 1, fast charge
5 USB-C
input/output
TM
6 USB-A output 2, fast charge
