Technische Daten - Shure Microflex MXN5-C Bedienungsanleitung

Eine vollständige Liste der Befehlszeichenfolgen ist verfügbar unter:
pubs.shure.com/command-strings/MXN5-C.

Technische Daten

Connector Type
RJ45
Power Requirements
Power over Ethernet (PoE) Class 0 or PoE Plus Class 4
Power Consumption
Power over Ethernet (PoE)
PoE Plus
Weight
6.5 lbs (2.95 kg)
Product Dimensions
12 x 12 x 4 in. (304.8 x 304.8 x 101.6 mm) H x W x D
Control Software
Shure Designer
Plenum Rating
UL 2043 (Suitable for Air Handling Spaces)
Operating Temperature Range
−6.7°C (20°F) to 40°C (104°F)
Storage Temperature Range
−29°C (­20°F) to 74°C (165°F)
Frequency Response (-3 dB)
120 Hz to 20 kHz
Maximum Output Level
At 1 meter
Power over Ethernet (PoE)
PoE Plus
Coverage Angle
Average of 1 octave band centered on 4 kHz
94°
12 W maximum (11 W typical)
24 W maximum (23 W typical)
92 dB SPL
98 dB SPL
