KMINA - PRO COMMODE TOILET CHAIR
USER MANUAL
KMINA - SILLA PRO - MANUAL DE USUARIO
KMINA - SEDIA PRO - MANUALE UTENTE
KMINA - PRO TOILETTENSTUHL - BENUTZERHANDBUCH
KMINA - CHAISE PRO - MANUEL D'UTILISATION
EN
The KMINA - PRO Commode Toilet Chair is designed to improve the daily hygiene of people with reduced mobility and to do this task as easy as possible, for
both the user and the assistant. The chair can be used for bath and shower. Save these instructions for future reference. This chair is in compliance with the EU
Regulation 2017/745 on medical devices.
SÍ
Folding
armrest
Seat with
hygiene cutout
Legrest
lock lever
Legrest,
swing-away
and removable
Steering castors
with overall lock
ASSEMBLY
1. Actuate the brake by lifting the lock rocker as in Image 1. This prevents the frame from moving during assembly. To unblock the brake, treading the lever as in
Image 1, when all assembly is finished.
2. Unscrew both locking screws on the frame and push the backrest tubes into it as in Image 2. Retighten the locking screws and after that flap the armrests,
moving them downwards, into position for use.
1
2
Unblocked
Braking
3. Take the seat with hygiene cutout and push it with the recess in the rear crossbar of the frame and once positioned firmly press the seat into the frame down
until it is fixed. Make sure the clips on the bottom of the seat fit completely into the frame.
4
1
Legrest lock lever
2
4. To attach the legrests, hook them into the tube (1) and swiwel them forwards (2) as in Picture 4. You can use the legrest lock lever to lock and unlock it so that
the legrests can be left open to leave the chair. They can also be easily removed and put on.
5. To adjust the height of the legrest, unscrew the connection at the rear side of the legrest tube (1) as in Picture 5, set the correct height of the foot plate (2) and
retighten the screws (3). IMPORTANT: The adjustment is correct if the user's legs form 45º when placing the feet. You can raise the foot plate of the legrests if
you wish to leave the chair and fold back easily.
REFERENCE
KMINA - PRO COMMODE TOILET CHAIR (BLACK)
K30010
KMINA - PRO COMMODE TOILET CHAIR (BLUE)
K30014
Backrest
Push handle
Disposal
bucket
Locking screw
Steering castors
with overall lock
Backrest
3
Seat with
hygiene cutout
Locking screw
5
2
1/3
Foot plate
REFERENCIA
1
