Handle replacement
CAUTION
• When replacing the door handle, take care not to scratch the front of the door.
• Firmly press the handles at the supports. Make sure there is no gap between the supports
and the door.
• Tightly fasten the screws when attaching the handle.
• Check that the handle is firmly attached before using the product.
Tools required (not provided)
Phillips screwdriver
To detach the handles
01
02
03
Barosa_User-servicing-manual_26lang.indb 3
Flat-head
screwdriver
LONG BAR
1. Unscrewing and removing two set screw
LONG BAR
BAR/EASY HANDEL
2. Remove cap screw
3. Unscrewing and removing two set screw
• Be careful not to scratch.
• When disassembling, make sure the unit
BAR / EASY
HANDEL
4. Assemble the new handle in the reverse
English
by Hexagon wrench disassemble the
handle.
by Hexagon wrench disassemble the
handle.
CAUTION
turned off if you want to assembly fellow
the reverse order.
order of disassembly.
