Ermenrich LV40 PRO Laser Level
EN
Caution! Please remember that mains voltage in most European countries is 220–240V. If you want to use your device in a country with
a different mains voltage standard, remember that use of a converter is absolutely necessary.
Charging the device
Connect the UBS Type-C cable to the device and DC adapter (not included) via a USB plug and connect it to the AC power supply. Attention! The
device operates from the AC power supply, as the voltage of the computer's USB port is insufficient for the proper operation of the device.
WARNING: When moving the laser level or storing it, keep the switch (3) locked.
Laser beams control buttons
On the laser level
Blue button
Green button
Auto-leveling mode
Slide the (3) switch to the unlock position. All the laser beams will light up. The power indicator light (10) is green. If the power indication is red
and laser beams flash frequently, place the device on a flatter surface. All three laser beams can be controlled by the (4)/(8) buttons. Lock the
device and turn it off.
Locked mode
Slide the (3) switch to the locked position. Press (7) and hold it for 3 seconds. All the laser beams will be flashing. The power indicator light
(10) is red. In the locked mode the device can be angled as needed. In this way, it is possible to project inclined lines and the autocalibration
will be switched off.
Brightness adjustment
When the device is in auto-leveling or locked mode, press (7). There are four brightness levels. Press (11) to change the brightness level in
order to save energy.
Pulse mode
Unlock the device. Press (7) and hold it for 3 seconds to enter the pulse mode. The power indicator light (10) will be flashing. Note! Brightness
adjustment is not possible in the pulse mode.
Specifications
Laser level
Laser color
Laser wavelength
Working distance
Laser class
Expanded angle
Brightness levels and working time
Compensation range
Level accuracy
Tripod adapter
Protection level
Power supply
Operating temperature range
Dimensions
The manufacturer reserves the right to make changes to the product range and specifications without prior notice.
Care and maintenance
Please carefully read the safety instructions and user manual before using this product. Otherwise, it may result in hazardous laser radiation
and electric shock. Keep away from children.
This is a class II laser product. Please DO NOT look directly into the beam with unprotected eyes or through an optical device at any time
Description
Controls the vertical laser beam at the front of the device
Controls the horizontal laser beam
green
505–550nm
30m
class II
2D, 8 cross lines, 360° horizontal, vertical
4 levels of brightness:
1 = 11h
2 = 14h
3 = 23h
4 = 42h
4°±1°
±1.5mm/5m
1/4"
IP54
4000mA·h built-in lithium battery, USB Type-C
–10... +50°C (14...122°F)
98.5x53x96mm (3.8x2x3.7in)
