Weh TK16 H2 Betriebsanleitung Seite 12

AE Operating instructions
TK16 H with IR / TK16 H
2
1
Pos� Description
Guide bush with impact protec-
1
tion and data interface
2 Cover disc
3 Actuation lever
4 Countersunk screw (3x)
5 Protective sleeve
6 Swivel joint 240°
7 Data cable
Definition of ports
B1 Media inlet
C2 Gas recirculation
Page 12
MD-10214-L51-R2.0.0-03
High-Flow with IR
2
3
2
6
5
4
7
B1
C2
