INSTALLATION
Power requirements
• 230 V - 50 Hz
• After installation the wall socket and plug must be accessible at all times.
• The KE158RVS is provided with a connection cable without a plug.
220-240V / 380-415V 50/60Hz 6000W
• The KE129RVS is provided with a connection cable with a plug.
220-240V 50/60 Hz 3500W
• KE158RVS: The connection block in the hob is equipped with a 5 core cable 5 x 1.5 mm and
connected according to 2L2N (2x 230V).
H05VV-F 5x 1,5mm
H05VV-F 3x 2,5mm
• In case another connection is made, please use a suitable cable,
H05VV-f 3x2,5 mm
• If wishing to make a direct connection to the mains, an omnipolar switch must be interposed
with a minimum opening of 3 mm between the contacts and suited to the load indicated on
the plate and conform to the regulations in force (the yellow/green ground conductor must
not be interrupted by the switch). When the appliance has been installed, the omnipolar
switch must be easily reachable.
EN 12
Grey
L
Black
L
Blue
N
Brown
N
2L2N~
2
~ H05VV-F 4x 1,5mm
2
(1L 1N 230v ~) of H05VV-F 4x1.5 mm
2
2-2N 230 V 50 Hz
ONLY NL / ALLEEN NL
2N~
2
(2N 380V ~).
2
