SYMBOLS
Read the instructions.
Approved in accordance with
the relevant directives.
Recycle discarded product
in accordance with local
regulations.
Double insulation (safetyclass
II), does not need to be
earthed.
• TECHNICAL
TECHNICAL DATA
Rated voltage
Output
Noise level
Size
W 220 x H 290 x D 100 mm
Cord length
Hose length
• DATA
DESCRIPTION
1.
Timer
2.
Status light
3.
Thermostat
4.
Hose
BILD 1
INSTALLATION
1.
Drill 3 holes in the wall (fig. A and B),
diameter 8 mm, depth 40 mm.
230 V ~ 50 Hz
350 W
49 dB
1.3 m
0.65 m
2.
Put plugs into the holes (fig. C) and screw
in the screws so that the screw heads
extrude about 3–5 mm from the wall
(fig. D).
3.
Hang the shoe drier on the screws (fig. E).
4.
Secure the shoe drier by screwing on the
metal plate (fig. F).
BILD 2
1.
Hole
2.
Screwdriver
3.
Screw
4.
Screw plug
5.
Hole
6.
Screw
7.
Wall
8.
Screwdriver
9.
Screw
10. Metal plate
OBS!
Make sure to use the right screws and plugs,
depending on the wall material.
USE
1.
Plug in the plug.
2.
Place the hoses in the damp boots or
shoes.
3.
Set the thermostat knob to max. Turn the
timer knob to the required time. The shoe
drier starts and the status light goes on.
4.
The status light stays on while the shoe
drier is running.
5.
The shoe drier switches off when the tim-
er knob returns to OFF. To continue drying
the shoes, turn the timer knob again.
OVERHEATING PROTECTION
