Tv Wall Mount Basic Fullmotion (M) - Goobay Basic FULLMOTION Betriebsanleitung

User Manual
EN

TV wall mount Basic FULLMOTION (M)

1 Safety instructions
The user manual is part of the product and contains important information for
correct use.
• Read the user manual completely and carefully before use.
The user manual must be available for uncertainties and passing the product.
• Keep this user manual.
• Do not modify product and accessories.
• Use product, product parts and accessories only in perfect condition.
• In case of questions, defects, mechanical damage, trouble and other pro-
blems, non-recoverable by the documentation, contact your dealer or pro-
ducer.
Not suitable for children and persons with physically and/or mentally limited ab-
ilities.
• Secure packaging, small parts and insulation against accidental use.
• Mounting, dismounting, care, storage, transport and disposal may only be
carried out by users with basic mechanical knowledge.
• Have maintenance and repair work carried out by qualified personnel only.
• Avoid stresses such as heat and cold, moisture and direct sunlight vibration
and mechanical pressure.
• Place, install and transport product, product parts and accessories in a safe
way.
• When working with burdens, secure yourself and the working place, let a se-
cond person help you.
• Do not install the product to places with direct sunlight or bright light.
This contributes to eye fatigue.
• Do not hold limbs between shear parts during use.
Moving product parts can pinch or squeeze limbs.
• Keep enough space around product and to the whole system to ensure pro-
per ventilation and mobility.
• Compare the specifications of all products used.
The specifications of all used products must match or be within the specified ran-
ge.
The included mounting material is only suitable for mounting on massive stone or
concrete ceilings. The bearing surfaces must be able to withstand the weight of
the wall bracket and the devices attached to it.
• For other ceiling types use suitable mounting material.
• Use the mounting screws provided.
• Do not over-tighten the screws.
Threads can be damaged.
2 Description and Function
2.1 Product
The product is a universal wall mount for attaching your TV or screen to vertical
and stable room walls.
2.2 Scope of Delivery
See Tab. 1.
○ TV wall mount (A)
○ Mounting rail (B)
○ Allen key (C)
○ Spanner (D)
○ M6x14 (M-A)
○ M8x16 (M-B)
○ M6x30 (M-C)
○ M8x35 (M-D)
2.3 Required Tools
See Tab. 2.
○ Line finder (1)
○ Spirit level (2)
○ Pencil (3)
○ Drill (4)
2.4 Specifications
Item No.
Screen size
Load capacity
Wall distance
Distance between threaded holes
according to VESA standard
(vertical x horizontal)
Dimensions (depth x width x
height) / Weight
Swivel range
Tilt range
Subject to change without notice.
Model similar.
○ Washer D8 (M-E)
○ Spacer (M-F)
○ Spacer (M-G)
○ Wall screw 6.3x55 (W-A)
○ Concrete dowel 10.0x45 (W-B)
○ Washer D6 (W-C)
○ User Manual
○ Suitable drill bit (wood Ø 4.5 mm /
concrete Ø 10.0 mm) (5)
○ Socket wrench (6)
○ Philips screwdriver (7)
49744
81 - 140 cm (32 - 55")
35 kg
63 - 427 mm
200x200, 300x300, 400x200,
400x400
427 x 455 x 420 mm / 2.8 kg
-90° ~ +90°
-15° ~ +10°
Rotation range
3 Intended Use
We do not permit using the device in other ways like described in
chapter „Description and Function" or in the „Safety Instructions". Use
the product only in dry interior rooms. Not attending to these
regulations and safety instructions might cause fatal accidents, injuries, and
damages to persons and property.
4 Preparation
• Check the scope of delivery for completeness and integrity.
5 Mounting
5.1 Mounting on a stable wooden wall
See Fig 1.
5.2 Mounting on a concrete wall
See Fig. 2.
5.3 Attaching the mounting rails to the screen
See Fig. 3.
5.4 Mounting the screen and secure it
See Fig. 4.
This step must be carried out by 2 people!
5.5 Hooking the cable into the bracket
See Fig. 5.
5.6 Adjusting the angle of rotation
See Fig. 6.
5.7 Adjusting the tilt angle and swivel angle
See Fig. 7.
6 Maintenance, Care, Storage and Transport
• Let maintenance and repair work only be carried out by qualified personnel.
• Protect the joints from dirt and grease them regularly with light machine oil.
• Only use a dry and soft cloth for cleaning.
Use caution when cleaning to avoid scratches. In case of heavy soiling, the clea-
ning cloth can be slightly moistened with water.
• Do not use detergents or chemicals.
• Regularly check the tightness of product/screws.
Fixing holes can remain visible when the product is removed. After prolonged
use, a stain may remain on the underground.
• Store the product out the reach of children and in a dry and dust-protected
ambience when not in use.
• Keep and use the original packaging for transport.
7 Disposal instructions
This product does not belong into the household waste. At the end of its working
life, give it back to the manufacturer, the sales outlet or established for this pur-
pose, public collection points for free. Details of disposal are regulated by the
respective country's law. Recyclables are into the recycle circuit, in order to gain
new raw materials. The following recyclable materials are collected in municipal
collection: Waste glass, plastics, scrap metal, sheets and much more. With this
type of scrap usage you are making an important contribution to protecting our
environment.
8 Warranty
Detailed warranty conditions on www.mygoobay.com.
9 Symbols used
For indoor use only
- 10 -
-3° ~ +3°
IEC 60417- 5957
