Install the Nano-SIM-Card with
the missing corner (see red circle
in picture) on the lower right side.
Ensure that the electrical contacts
of SIM-Holder and SIM-Card are
connected.
Gently push down the SIM-Card plate
and slide it downwards.

3.3 Assembly

Check the correct position of the blue
frame indicated.
