Manual
Applicable for:
Product-No.:
103-203-03-001-01 (white)
103-203-04-001-01 (black)
103-201-09-005-00 (gold, mat)
103-201-07-005-00 (titanium grey)
Specifications
Power Supply
Rated / Music power
SPL 1W/1m
Frequency Range (-3 dB)
Transmission Angle
1/2/4/8 kHz (-6 dB)
Protocols
Maximum distance between
quency site survey is recom-
tansmitter an receiver
Dimensions (H/W/D)
Weight
Material
Note:
! Please note the country-specific safety guidelines for use and operation
of WLANs.
! For continued flawless audio transmission you should always use a
wireless router from 802.11n and the latest smartphones / tablets.
Product registration and extended warranty at:
www.whd.de/Produktregistrierung
This product supports all CE-
marking criteria. The declaration of
conformity certificate can be ob-
tained from WHD.
Operation
Qube 2 go
Thank you for buying our mobile WLAN hifi-spearker.
Please read this manual carefully, especially the safety and security information.
Mounting
Put the speaker to a desired location.
Notes on battery operation
The Qube 2 go contains a permanently installed lithium-ion battery. The battery is NOT
replaceable. The charging time is approximately 4-5 hours.
The battery life is at full volume approx. 4 hours / at half volume about 8 hours.
Qube 2 go
Connecting the speaker:
110...230 V AC
- Connect power supply for charging (3).
- Switch ON the Qube (1).
5 W
LED switches to „green".
84 dB
! The reset button (2) you can press, for example, with the end
of a paper clip. To activate it, hold down the button pressed
90-18000 Hz
longer than 5 seconds.
180/130/105/80 °
LED
Airplay, UPnP, DLNA
GREEN
up to 30m*
ORANGE
(* ... a wireless radio fre-
RED
mended in harsh environ-
ments)
120x120x120 mm
1,3 kg
In addition to this guidance please comply with your own country-specific safety & security
Aluminium housing,
regulations.
fabric panel
The device is not suitable for outdoor operation.
- The electrical supply must be disconnected before working on the device.
- Keep the original packaging (for returning products under warranty).
- Protect the product and the components supplied against dripping or splashing. Make
sure, as with all electronic products that no liquids can access any part of the system. This
may cause a malfunction or fire.
- Do not expose the product to temperatures above 30° C.
- Do not expose the product to electrostatic discharges.
- Never put the product near heat sources such as radiators, heat registers, stoves or other
types of devices that produce heat.
WHD are members of the INTERSEROH association.
We participate in the dual system as well as other
industry-specific solutions. Therefore, plastic, metal
and electronic parts can all be recycled.
Status
Ready for operation
Charging
Device needs charging
Safety & Security Informations
Improper handling may void warranty!
WHD - Wilhelm Huber+Söhne GmbH+Co.KG
Direct Play
1. Enter WLAN menue at your smartphone,
tablet or PC and seek for available wireless
networks.
2. Select WHD-Air + MAC address. Your
smartphone, tablet or PC connects to the Qu-
be. Now you can send music from your smart-
phone, tablet or PC, directly to the Qube.
! Some playback devices and players also have
a WiFi-Direct connection without pre-
connecting.
Qube 2 go
LED
WLAN Operation
1. Enter WLAN menue at your smartphone,
tablet or PC and seek for available wireless
networks.
2. Select WHD-Air + MAC address. Your
smartphone, tablet or PC connects to the Qu-
be.
1
2
3
3. Start the WHD Multiroom Audio Player
App, which you can download via App Store or
Google Play Store for free.
4. Select in the WHD Multiroom Audio Player
App the „Assistent" and follow the user
prompts.
! The App connects the Qube to your WLAN.
This procedure may take a few minutes.
Multi Play
Multi Play is defined as the simultaneous play-
back of a music player on several Qubes. Using
the WHD Multiroom Audio Player App you
can, for example, play music in several rooms
simultaneously.
! All Qubes have to share the same wireless
network with min. 150 Mbps.
! Use the WHD Multiroom Audio Player App
only.
Bismarckstr. 19
D-78652 Deißlingen
Tel. Zentrale +49 74 20 / 8 89-0
Fax Zentrale +49 74 20 / 8 89-51
Version
(Technical and optical
modifications reserved)
30.09.2019
E-Mail:
info@whd.de
Web:
www.whd.de
