OPERATING AND MAINTENANCE MANUAL
INDEX

1. NAME OF PARTS .............................................................. 5

2. GENERAL POWER TOOL SAFETY WARNINGS............. 6
3. REBAR CUTTER SAFETY WARNINGS............................ 8
4. TECHNICAL DATA .......................................................... 11
5. BATTERY INSTRUCTIONS ............................................. 13
6. OPERATING INSTRUCTIONS......................................... 15
7. MAINTENANCE................................................................ 16
8. STORAGE ........................................................................ 16
1. NAME OF PARTS
(See Fig. A and B)
1 HEAD
2 BLADE
3 CUTTER ROD
4 OILING BOLT
5 TRIGGER SWITCH
6 MOTOR
7 BATTERY PACK JPL92530A
Fig. A
8 SAFETY LOCK SWITCH
9 VALVE BOLT
10 ADJUST BOLT
11 LOCK NUT
12 SPECIFICATION LABEL
13 GRIP
14 SIDE HANDLE
ENGLISH
15
16
17
Fig. B 18
19
20
21
5
Original instruction
PACK CAP
TERMINAL
VENTILATION WINDOW
LATCH
SPECIFICATION LABEL
BATTERY LEVEL GAUGE
BATTERY LEVEL CHECK BUTTON
