Virtual Color Wheel
The Ovation E-910FC IP includes a feature called the Virtual Color Wheel (VCW). This feature is available as a
standalone control mode for manual use and as a control channel in select DMX personalities. More than 30 premixed
colors, custom blended by Chauvet engineers, are available to call up for easier programming.
The DMX values used to mix these colors are provided below. The overall intensity of the Ovation fixture can be adjusted
to more closely replicate familiar industry-standard colors. A chart is available on
compare Chauvet's premixed colors with popular gel colors. This chart is for comparison purposes only and is not an
assertion that Chauvet's premixed colors match any of the gel colors listed.
Virtual Color Wheel Chart
DMX Value Display Readout
000  005
006  013 C3050 - Md Yellow
014  021 C3040 - Lt Yellow
022  028 C3240 - Amb Yellow
029  035 C2340 - VLt Amber
036  043 C2040 - Lt Amber
044  051 C2050 - Md Amber
C2060 - Dk Amber
052  059
060  067 C1050 - Lt Red
068  075 C1080 - Md Red
076  083 C1020 - NC Pink
084  091 C1030 - Md Pink
092  099 C1630 - Dk Pink
100  107 C1250 - Md Red Amber
108  115 C1060 - Dk Red Amber
116  121 C1650 - Magenta
122  130 C6170 - Dk Magenta
131  138 C6020 - Lt Lavender
139  146 C5030 - Lt Blue
147  154 C5020 - VLt Blue
155  162 C5430 - Lt Blue2
163  170 C5070 - Blue
171  178 C5050 - Md Blue
179  186 C5060 - Dk Blue
187  194 C5690 - Indigo
195  202 C5080 - VDk Blue
C5081 - VDk Blue2
203  210
C4370 - Yel Green
211  218
219  226 C4070 - Green
227  234 C4550 - Turquoise
235  242 C4560 - Aqua
243  250 C4570 - Blue Green
251  255
Note: The colors above are simulated renditions of the color output produced compared with other
similar incandescent products. Chauvet makes no guarantee of the color output accuracy.
Color Temperature DMX Chart
DMX Value Color Temperature
000  005 No function
006  025
026  050
051  075
076  100
101  125
126  150
151  175
176  200
201  225
226  250
226  250 No function
Note: The colors above are simulated renditions of the color output produced compared with a
tungsten lamp at the specified color temperature. Chauvet makes no guarantee of the color output
accuracy.
