QUICK REFERENCE GUIDE About This Guide The Ovation E-260CW Quick Reference Guide (QRG) has basic product information such as connection, mounting, menu options, and DMX values. Download the User Manual from www.chauvetprofessional.com for more details. Disclaimer The information and specifications contained in this QRG are subject to change without notice. LIMITED WARRANTY FOR WARRANTY REGISTRATION AND COMPLETE TERMS AND CONDITIONS PLEASE VISIT OUR WEBSITE.
QUICK REFERENCE GUIDE AC Plug Connection Wire (U.S.) Wire (Europe) Screw Color AC Live Black Brown Yellow/Brass AC Neutral White Blue Silver AC Ground Green/Yellow Green/Yellow Green To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely disconnect the product from power via breaker or by unplugging it.
Seite 4
QUICK REFERENCE GUIDE Control Panel Description Button Function <MENU> Exits from the current menu or function <ENTER> Enables the currently displayed menu or sets the currently selected value into the selected function <UP> Navigates upwards through the menu list or increases the numeric value when in a function <DOWN>...
Seite 5
QUICK REFERENCE GUIDE DMX Values Channel Function Value Percent/Setting Dimmer 000 255 0–100% Fine Dimmer 000 255 0–100% 000 010 No function Strobe 011 255 Strobe, slow to fast 000 010 No function 011 070 Auto 1 Auto Program 071 ...
GUÍA DE REFERENCIA RÁPIDA Acerca de Esta Guía La Guía de Referencia Rápida (GRR) del Ovation E-260CW contiene información básica sobre el producto, como montaje, opciones de menú y valores DMX. Descargue el Manual de Usuario de www.chauvetprofessional.com para información más detallada. Exención de Responsabilidad La información y especificaciones contenidas en esta GRR están sujetas a cambio sin previo aviso.
GUÍA DE REFERENCIA RÁPIDA Enchufe CA Conexión Cable (EE.UU.) Cable (Europa) Color del tornillo CA Cargado Negro Marrón Amarillo/Latón CA Neutro Blanco Azul Plata CA Tierra Verde/Amarillo Verde/Amarillo Verde Para evitar un desgaste innecesario y alargar su vida útil, desconecte complemente el producto de la alimentación, mediante el interruptor o desenchufándolo, durante los periodos en los que no se use.
Seite 8
GUÍA DE REFERENCIA RÁPIDA Descripción del Panel de Control Botón Función <MENU> Sale del menú o función actual Habilita el menú actualmente en pantalla o configura el valor seleccionado actualmente dentro de la <ENTER> función seleccionada <UP> Navega hacia arriba por la lista de menú o aumenta el valor numérico cuando está en una función <DOWN>...
Seite 9
GUÍA DE REFERENCIA RÁPIDA Valores DMX Canal Función Valor Porcentaje/Configuración Atenuador 000 255 0–100% Atenuador fino 000 255 0–100% 000 010 Sin función Estroboscopio 011 255 Lento a rápido 000 010 Sin función 011 070 Auto 1 ProgramasAutomática 071 ...
MANUEL DE RÉFÉRENCE À Propos de ce Manuel Le Manuel de Référence du Ovation E-260CW (MdR) reprend des informations de base sur cet appareil notamment en matière de connexions, montage, options de menu et valeurs DMX. Télécharger le Manuel d'Utilisation sur www.chauvetprofessional.com pour de plus amples informations.
MANUEL DE RÉFÉRENCE Prise CA Connexion Câble (États-Unis) Câble (Europe) Couleur de la vis Conducteur CA Noir Marron Jaune/Cuivré Neutre CA Blanc Bleu Argenté Terre CA Vert/Jaune Vert/Jaune Vert Durant les périodes de non-utilisation, pour éviter tout usure inutile et pour prolonger la durée de vie, déconnectez-entièrement l'appareil en le débranchant de l'alimentation électrique ou en coupant le disjoncteur.
MANUEL DE RÉFÉRENCE Description du Tableau de Commandes Bouton Fonction <MENU> Permet la sortie du menu ou de la fonction en cours <ENTER> Permet l’affichage du menu en cours ou permet de configurer la valeur en cours dans la fonction sélectionnée Permet de parcourir les listes ou les menus vers le haut, dans une fonction permet d'augmenter les <UP>...
Seite 13
MANUEL DE RÉFÉRENCE Valeurs DMX Canal Fonction Valeur Pourcentage/Configuration Gradateur 000 255 0–100% Gradateur Fin 000 255 0–100% 000 010 Pas de fonction Stroboscope 011 255 Lent à rapide 000 010 Pas de fonction 011 070 Auto 1 Programmes Auto 071 ...
SCHNELLANLEITUNG Über diese Schnellanleitung In der Schnellanleitung des Ovation E-260CW finden Sie die wesentlichen Produktinformationen, wie etwa über die Montage, Menüoptionen und DMX-Werte des Geräts. Laden Sie für weiterführende Informationen unter www.chauvetprofessional.com das Benutzerhandbuch herunter. Haftungsausschluss Die in dieser Anleitung aufgeführten Informationen und Spezifikationen können ohne vorherige Ankündigung geändert werden. EINGESCHRÄNKTE GARANTIE ZUR REGISTRIERUNG FÜR GARANTIEANSPRÜCHE UND ZUR EINSICHT IN DIE VOLLSTÄNDIGEN GESCHÄFTSBEDINGUNGEN BESUCHEN SIE BITTE UNSERE WEBSITE.
SCHNELLANLEITUNG Packungsinhalt • Ovation E-260CW • Netzkabel Neutrik powerCON • Schnellanleitung Wechselstrom Dieses Gerät verfügt über ein Vorschaltgerät, das automatisch die anliegende Spannung erkennt, sobald der Netzstecker in die Schukosteckdose gesteckt wird, und kann mit einer Eingangsspannung von 100~240 V AC, 50/60 Hz arbeiten. Serienschaltung der Geräte Sie können bis zu 7 Ovation E-260CW Geräte bei 120 V AC, 12 Geräte bei 208 V und 13 Geräte bei 230 V AC in Serie schalten.
SCHNELLANLEITUNG Montage Lesen Sie vor der Montage dieses Geräts die Sicherheitshinweise durch. Mindestens zwei Befestigungspunkt pro Gerät verwenden. Stellen Sie sicher, dass die Befestigungsklemmen dafür ausgelegt sind, das Produktgewicht tragen zu können. Informationen zu unserer CHAUVET-Produktlinie für Befestigungsklemmen finden Sie unter http://trusst.com/ productcategory/truss-clamps/ Montageansicht...
BEKNOPTE HANDLEIDING Over deze handleiding De Ovation E-260CW Beknopte Handleiding (BH) bevat basisinformatie over het product, zoals aansluiting, montage, menu- opties en DMX-waarden. Download de gebruikershandleiding op www.chauvetprofessional.com voor meer informatie. Disclaimer De informatie en specificaties in deze BH kunnen zonder voorafgaande kennisgeving worden gewijzigd. BEPERKTE GARANTIE GA NAAR ONZE WEBSITE VOOR REGISTRATIE VAN DE GARANTIE EN DE VOLLEDIGE ALGEMENE VOORWAARDEN.
Seite 20
DMX basishandleiding verkrijgbaar. DMX-aansluiting De Ovation E-260WW gebruikt een normale DMX-gegevensverbinding voor zijn DMX-persoonlijkheden: 1 Ch, 2 Ch, 3 Ch, en 6 Ch. Zie de gebruikershandleiding om te verbinden en te configureren voor DMX-werking. Master/slave-verbinding De Ovation E-260WW maakt gebruik van de DMX-dataverbinding voor haar Master-/Slave-modus. Zie de gebruikershandleiding om te verbinden en te configureren voor Master/Slave-werking.
BEKNOPTE HANDLEIDING Montage Lees alvorens dit product te monteren alle Veiligheids instructies. Gebruik ten minste twee montagepunten per product. Controleer of de montageklem het gewicht van het product kan dragen. Ga voor onze Chauvet-serie montageklemmen naar http://trusst.com/productcategory/truss-clamps/. Montagediagram van het product Veiligheidskabel Montageklem Bevestiging van de andere...
