After switching on the FRIAMAT fusion unit the switch-on signal of the
FRIAMAT barcode scanner sounds (4 short signal tones in rapid succession),
followed by the verification tone of the FRIAMAT fusion unit. The switch-on
signal of the FRIAMAT barcode scanner indicates that the FRIAMAT barcode
scanner is ready to use.
3. Operation
FRIAMAT barcode scanner reads the barcodes contact-free. Position the
FRIAMAT barcode scanner over the barcode and push the reading button. The
barcode is recorded by a red light-band, which should be centred horizontally
over the complete barcode. The barcode will not be read if the red light-band
is in any other position.
Good Read
Optimal reading results can be realised when the FRIAMAT barcode scanner
is positioned in short distance above the barcode. In case of bad printed or
slightly damaged barcodes it can be helpful to position the FRIAMAT barcode
scanner close to the barcode and then – with pushed reading button – to lift
slowly from the barcode. A successful reading of the barcode is signalised
by sounding of a verification tone and lighting up of a green signal light in the
middle of the barcode.
4.

Technical data

Compatibility
Temperature range
Weight
Sealant rating
Bad Read
FRIAMAT prime, FRIAMAT basic, FRIAMAT prime
eco, FRIAMAT basic eco, FRIAMAT geo print
Operating: -20° C to +50° C
Storage: -20° C to +70° C
ca. 390 g
IP 65
Bad Read
