The proper functioning of your RENSON
ventilation system is heavily dependent
on the choice and construction
quality of the air ducts and openings
to the outside!
✗
✗
Avoid dents and
dirt in ducting.
Use ducting that is airtight and large enough
in diameter. If necessary, seal off connection
pieces with airtight tape.
Opt for a flexible air duct from
the
RENSON EASYFLEX
range.
Use as few bends as
possible and never bend
ducting sharper than 90°.
✗
Properly stretch out
flexible ducting.
✗
✗
Do not use
screws.
✗
RENSON
Headquarters ∫ Maalbeekstraat 10 ∫ IZ 2 Vijverdam ∫ B-8790 Waregem
®
Tel. +32 56 30 30 00 ∫ info@renson.eu ∫ www.renson.eu
Healthbox
Choose a low resistance roof
exhaust such as the
Design roof
Duct to roof exhaust: ≥ Ø 150 mm.
✓
Avoid bends and limit the length of the duct to a
minimum.
Use the included adapter ring.
Ø 150 mm
Limit the transmission of vibrations.
✓
Fit a
RENSON ACOUDEC
sound absorber in rooms
where insulation is
important.
✓
✓
Make sure that the total back pressure is as low as
possible (target ≤ 150 Pa) and that the air velocity in
each duct is less than 3 m/s.
Too high back pressure is caused by ducts that are too
small in diameter, ducts that are too long, or ducts that
have too many bends. Therefore, pay close attention
to where you position Healthbox 3.0 in your home.
Installation tips
3.0
®
Renson
exhaust.
✓
✓
0,5 or 1 m
✓
Duct diameter:
Ø 125 mm ➔ ≥ 30 m³/h
Ø 80 mm ➔ < 30 m³/h
