THRUNITE TW10 Bedienungsanleitung

Guiding You Through The Night
TW10
说明书
（CHS）简体中文
+86-0755-26809357
service@thrunite.com
http://www.thrunite.com
广东省深圳市宝安区西乡宝源路168号
名优采购中心A栋640室
Guiding You Through The Night
TW10
User Manual
（EN）English
+86-0755-26809357
service@thrunite.com
http://www.thrunite.com
Room 640, Tower A,
NO.168 Baoyuan Road, Xixiang,
Baoan, Shenzhen 518102, China
TW��充电式LED枪灯采用最新的OSRAM灯珠， 最大流明可达���流明， 最大射程可达���米。
规格参数
LED灯珠 光镜
1*OSRAM P9
TIR透镜
配件
防水圈*2, THRUNITE 18350电池*1, USB-C充电线*1，USB胶塞*1，六角螺丝*2，六角扳手*1，1913适配条*1
档位亮度
续航时间
最大射程
最大光强
防跌落等级
防水等级
上述参数只是一个近似值，以THRUNITE 1100mAh 18350电池在实验环境中测试所得，可能会随着手电，电池和使用环境而发生变化
电量指示灯
电量等级
LED状态
相对电压点
指示灯在尾部充电端口。
操作说明
注意：请在使用前拧紧灯头和灯尾再进行后续操作。
拧松灯头可以更换电池。
两边开关功能一致。
轻触任意一侧开关即可点亮/关闭手电。
长按任意一侧开关点亮手电，松手即关闭。
充放电功能
USB-C 600MA充电。可兼容双头TYPE-C接口充电。充电中指示灯亮红色，
充满后亮蓝色，紫灯闪烁代表充电异常。
TW10 rechargeable LED flashlight adopts the latest OSRAM LED to make output up to 900 lumens and max beam distance of 125 meters.
Specifications
LED Lens Working Voltage
1*OSRAM P9 TIR Lens 2.75V-4.2V
Spare O-ring *2, THRUNITE 18350 1100mAh Battery *1, USB-C Charging Cord *1, Spare USB Rubber Cover *1, Allen Screw *2, Socket Head Wrench *1,
Accessories
1913 Rail Adapter *1
Output
Run time
Distance
Intensity
Impact Resistance
Waterproof
Notes: The above parameters tested by one THRUNITE 1100mAh 18350 battery are approximate and may vary between lights, batteries and environment.
Indicator
Power Capacity
Indicator
Voltage
The LED Battery indicator is at the charging port of tail cap.
Operation
CAUTION :Please screw down the light head and tail cap tightly before use.
Screw off the light head to change the battery.
Constant on
Quick single click either switch to turn the light on with the memorized
brightness level. Single click again to turn off the light.
Momentary on
Press and hold either switch to turn on the light, release the switch to turn the
light off.
Rechargeable Function
Max 600MA USB-C charging. Compatible with dual-head TYPE-C charging.
During charging, the indicator is RED. After being fully charged, the indicator
will be BLUE. When indicator flashes purple, it means abnormal charging.
机械参数
工作电压 材质
2.75V-4.2V
AL T6061-T6
ANSI/NEMA FL1参数
900 流明
195 秒 + 130 分钟
0% 1 - 10%
无指示 红闪
0-2.5V 2.5-2.7V
保修条款
1. 2年免费包换：THRUNITE产品自出售之日起2年内，用户在正常使用情况下，
出现产品质量问题，则享受2年免费包换。
2. 30天无条件退款，邮费自理。
3.终身有限保修：在超过2年免费包换时间外，THRUNITE公司将提供有偿保修，
费用以实际更换材料费用为准，不另收取人工费用。
警示
1. THRUNITE手电亮度高，请勿直视发光体，以免造成视力损伤。
2. 请远离儿童防止其误食。
3. 为了保护电池，电路板以及LED灯珠，我们建议操作极亮模式不要超过10分
钟。
Technical Parameters
Material Surface Finish
AL T6061-T6 Premium type III hard-anodized
ANSI/NEMA FL1 Parameters
General Mode
900
lumens
195 secs + 130 mins
125 meters (max.)
0% 1 - 10%
Off Flashing red
0-2.5V 2.5-2.7V
Warranty
1. 2-years free replacement: We will offer free replacement within 2 years of
purchase if problems develop with normal use.
2. 30-days refund by Amazon: You may return most new, unopened items sold
and fulfilled by Amazon within 30 days of delivery for a full refund.
3. Lifetime limited maintenance: As to those exceed 2 years of the purchase
date, we will still provide with maintenance service, but the cost of parts will be
charged and freight should be paid by customers.
Warnings
1. THRUNITE flashlights are high-intensity lighting devices capable of causing
eye damage or other harms, so please avoid shining our light directly into
anyone's eyes.
2. Please keep flashlights away from children.
3. To protect the battery, driver circuit and LED, we Do NOT recommend you run
the light at max mode more than ten minutes.
表面处理 尺寸
77mm*26mm*32.5mm
三级硬质氧化
照明模式
427 流明
125米
3960 坎德拉
1.5米
IPX-8 水下2米
11 - 20%
红灯常亮
2.7-3.0V
Dimension
77mm*26mm*32.5mm
427 lumens
3960 cd (max.)
1.5 meter
IPX-8 (2M)
11 - 20%
Red
2.7-3.0V
重量
裸机78g
21 - 100%
蓝灯常亮
3.0-4.2V
Weight
78g
(battery excluded)
21 - 100%
Blue
3.0-4.2V
