Fig. 5:6 The rear side of the Control Unit
1 Power
2 Mains inlet
3 Voltage equalizer connection
4 Contact for hot plate cable
5 Contact for temperature sensor cable
6 Contact for communication cable to Drive Unit
7 Air preassure outlet
