Soxtec™ 2050 Automatic System

5 Operating Instructions

5.1 Identification of Operating Controls and Sym-
bols
These captions are translated.

5.1.1 Extraction Unit

1 2 3
Fig. 5:1
1 Cooling water inlet from Drive Unit 5
2 Air pressure inlet
3 Voltage equalizer connection
4 Cable for hot plate
Fig. 5:2 Empty the collection vessel with the emptying tube and the valve in open position
User Manual 1000 7414 / Rev. 4
3
4
4 5 6
Cable for temperature sensors
6 Wires to Drive Unit
7 Cooling water outlet
2050026c
6
7
2050030c
5:1
