1.4 E/A-Blende

12
Nr. Beschreibung
1 2,5G LAN RJ-45-Port*
2 Line-Eingang (hellblau)**
Vorderer Lautsprecher
3
(limettengrün)**
4 BIOS-Flashback-Taste
5 Mikrofon (rosa)**
6 USB-3.2-Gen1-Type-A-Port
(USB32_7)
7 USB-3.2-Gen2x2-Type-C-Port
(USB32_TC1)
8
11 10
Nr. Beschreibung
1
9 8
8 USB-3.2-Gen1-Type-A-Ports
(USB32_56)
9 USB-3.2-Gen1-Type-A-Ports
(USB32_34)***
10 USB-2.0-Ports (USB1234)
11 USB-3.2-Gen1-Type-A-Ports
(USB32_12)
12 HDMI-Port
2
3
6 5 4
7
