! WARNING
Power Supply
Configuring a Network
Connection
! NOTE
Do not mount the PROmesh P9+ directly next to devices that generate strong electro-
magnetic interference fields or constantly emit heat to their surroundings. Also protect
the PROmesh P9+ from intense sunlight.
The PROmesh P9+ is operated with a redundant DC voltage of 24 VDC, Connect a suita-
ble power source to the labeled terminals of the 7-pin 2,5 mm
the positive lead to one of the VDC contacts and the ammunition lead to the corres-
ponding GND contact.
If the external power supply is correctly connected and activated, all status LEDs of the
PROmesh P9+ will light up briefly. After a short initialization phase the LEDs go out and
the device is ready for operation and can now be configured in the network.
Download the Service Tool to your client PC (Windows). You can find the software at
the following link:
www.indu-sol.com/en/servicetool
Our software is updated regularly. Please, make sure you are using the latest version.
Connect the PC to a suitable data line on one of the data ports (P1 – 9).
The PROmesh P9+ and the client PC must be located in the same IP address range and
IP subnet. For this you have to assign a corresponding IP address to your PROmesh P9+
for the first time. Use the already installed ServiceTool.
After assigning a suitable IP address and subnet mask, the Web UI of the PROmesh P9+
can be reached.
The PROmesh P9+ is delivered with the following factory settings:
ENGLISH
terminal block. Connect
