INPUTS AND OUTPUTS

AUX input
Connect a source device with analogue audio (for example, a cassette or CD
player) to the RCA connector. A cable with RCA plugs is needed to make the
connection (not included).
TUNER Radio device
PHONO Record player
CD/DVD CD/DVD player
LINE 1
LINE 2 External source with AUX connection
LINE 3
Optical and coaxial input
Connect the digital audio output of a source device to the optical/coaxial
connector of the unit using an optical/coaxial cable (with TOSLINK
connector).

SPEAKER OUTPUT

If possible, use a high-quality double-core speaker cable with a diameter of
at least 1 mm² to connect to the speaker output.
Please note: observe the correct polarity. Otherwise, the sound quality
suffers.
• Connect the plugs to the connectors of the same colour.
• The strands of the speaker cables are marked with different colours or
shapes. Divide the single cable to 30 mm and remove about 10 mm of
the insulation of each strand. Twist the single cable so that no strands
protrude. A tin coating is not necessary. Unscrew the corresponding
plug-in terminal and insert one end of the cable into the corresponding
opening. Then turn the corresponding terminal in the other direction to
secure the cable.
